Servo-Electric Grippers PGE-15-10

Product Details

Product Description

Product Description
Product features
1.Small size/flexible installation
2.A quick response
3.Accurate force control
Application scenarios
Scenarios with demand for force control and flexibility, such as assembly, sorting and loading and unloading applications in semiconductor, 3C electronics, medical automation and other industries。
Technical parameters
Hold power(one side) ：06~15N
Total trip ：10mm
Maximum recommended load ：0.25kg
Open/close time : 0.2s/0.2s
Position repetition accuracy : ±0.01mm
Running noise：＜60 dB
The weight of the : 0.155kg
The transmission way ：The gear and rack+Cross roller rail
size : 89mm×30mm×18mm
Runtime environment
Working voltage ：24V DC±10%
Ratted current ：0.1A
Peak current ：0.22A
Protection grade ：IP40
Recommended Work Environment ：0~40°C，85%RH The following
In line with international standards ：CE,FCC,RoHS

---
