JEC Ceramic Capacitor 104 Features:
Wide working temperature range, low loss and high capacity stability
Electrical Characteristics:
Ceramic Capacitor 104 Electrical Characteristics:
Technical Requirements Reference Standard: GB/T 2693-2001 ; GB/T 5966-1996
Rated Voltage(UR): 500 / 1K / 2K / 3K / 4K / 5K / 6K / 7K / 8K / 9K / 10K / 15K / 20K / 25K / 30K / 40K /50K VDC
Capacitance Range: 1pF to 100000pF
Capacitance Tolerance: NPO±0.5pF(D)±5%(J) ; SL±5%(J)±10%(K),Y5P,Y5U±10%(K ) ; Y5U,Y5V±20%(M)
Dissipation Factor (tgδ): C<30pF,Q≥400+20C ; C≥30pF,Q≥1000 ,Y5P,Y5U,Y5V:tgδ≤2.0% ; Y5P:tgδ≤0.5% ; Y5R:tgδ≤0.3%
Insulation Resistance(IR): IR≥10000MΩ,1min,100VDC，IR≥4000MΩ,1min,100VDC
Operating Temperature Range: -25℃ to +85℃
Temperature Characteristic: NPO,SL,Y5P,Y5U,Y5V
Flame Retardant Epoxy Resin: UL94-V0
At present, Dongguan Zhixu Electronic (also JYH HSU(JEC)) produces a wide range of passive components including common and high voltage ceramic capacitors, EMI suppression capacitors (X2, Y1, Y2), film capacitors (CBB series, CL series, etc), varistors (surge absorber) and thermistors. Our yearly production of X and Y capacitors is over 3 billion, making us one of the top 10 manufacturers of safety capacitors in the Chinese industry.
JEC Multilayer Ceramic Capacitor has the advantages of low loss and high capacity stability, which makes it suitable for application in bypass or coupling circuit.
