| US$22,000.00 | 1 Piece (MOQ) |
| Technical Parameters | Model UP-200T | ||
| Injection Unit | A | B | C |
| Screw diameter (mm) | 42 | 45 | 50 |
| Shot Volume (cm3) | 346 | 397 | 490 |
| Injection weight (g) | 311 | 357 | 440 |
| injection pressure (Mpa) | 168 | 140 | 118 |
| Screw speed (rmp) | 155 | ||
| Clamping Unit | |||
| Clamping force (KN) | 2000 | ||
| Open stroke (mm) | 450 | ||
| Max Mold height (mm) | 520 | ||
| Min Mold height (mm) | 220 | ||
| Space between tie bars(mm) | 520*470 | ||
| Ejector force (KN) | 80 | ||
| Ejector stroke (mm) | 140 | ||
| Others | |||
| Pump pressure (Mpa) | 16 | ||
| Motor/driving power (KW) | 23(21.2) | ||
| Heating power (KW) | 9.3 | ||
| Machine dimension (M) | 4.95*1.4*2 | ||
| Machine weight (T) | 5.7 | ||
| Oiltank cubage (L) | 260 | ||
