915MHz Magnetron 75kw

US$4,000.00-6,000.00 1 Piece (MOQ)

Basic Info.

Model NO.

ACME-2031

Installation

Plug-in Triode

Working Frequency

2450MHz

Power Level

High Power

Function

Power Triode, Switching Triode

Structure

Alloy

Material

Germanium

Input

220V/380V

Input Mode

1 Phase 2 Wires/3 Phase 4 Wires

Power

10kw

Output Frequency

2450MHz

Efficiency

90%

Duty Cycle

0-50%

Transport Package

Wood Packing

Specification

6kw/10kw/15kw

Trademark

ACME

Origin

Jinan

HS Code

8540710000

Production Capacity

300PCS/Month

Packaging & Delivery

Package Size

50.00cm * 50.00cm * 50.00cm

Package Gross Weight

15.000kg

Product Description

Product introduction
The tube is a fixed frequency continuous wave magnetron with a wavelength of 12cm, which can directly excite the rectangular waveguide for microwave heating as a power source.
Main performance
Frequency 915 ± 10MHz
Output power ≥ 75kw
Anode voltage 17-18kv
Anode current 5A
Filament current 29a
Filament voltage ≤ 12V (subject to filament current)
The magnetic field is about 1450gs
Load voltage standing wave ratio ≤ 2
Limit service value
Filament surge current < 115A
Cathode preheating time ≥ 60s
Anode current ≤ 5a
Anode input power ≤ 75kw
Load voltage standing wave ratio ≤ 2.5
Anode temperature (designated test point) ≤ 100 ºC
Cathode outlet temperature (designated test point) ≤ 150 ºC

Code	Min	Normal	Max
A B C D	- φ123.5 108 φ91	- - 109 φ92	470 φ125.5 110 φ93
E F G H	- φ76.0 φ35.2 φ56.8	1/2'-20 φ76.2 φ35.4 φ57.0	- φ76.4 φ35.6 φ57.2
I J K L M N P Q R	- - - 105 - - - - -	φ8 - - 110 φ76 - 6×M6 15° 90°	- 150 φ101.3 115 - 230 - - -
