Heavy Duty 450kg Per Hour Plastic Milling Machine with 30kw Power

Product Description

Applications:The Heavy Duty 450kg Per Hour Plastic Milling Machine by Zhangjiagang City Yili Technology Co., Ltd. excels in multiple applications, showcasing its versatility and efficiency. Primarily, it is indispensable in the pulverization of PVC regrind for pipe and profile recycling, creating a seamless workflow when paired with a shredder and granulator. This dynamic trio forms a well-balanced, superior system for managing in-house production waste. Additionally, in the realm of Rotomolding, the PM Pulverizer shines by producing the precise powder essential for this intricate process. A screening machine complements this to guarantee the desired output size, optimal material distribution, and excellent flow properties, ensuring unparalleled quality and consistency.
Technical Specifications:

Model	SMP-300	SMP-400	SMP-500	SMP-600	SMP-800
Disc Diameter(mm)	300mm	400mm	500mm	600mm	800mm
Dimension L*W*H(mm)	3700*1500*3700	3800*1600*3800	3900*1700*3900	4000*1800*4000	4300*1900*4300
Main Motor(kw)	11-15	22-30	30-37	45-55	75-90
Air Blower(kw)	3	4	5.5	5.5	7.5
Vibrating Motor (kw)	0.55	0.55	0.75	1.1	1.1
Capacity (kg/h)	30-50	50-120	120-200	200-350	400-600

General descriptionOur Waste Plastic Pulverizer Machines, boasting disc diameters ranging from 300 to 800 mm, redefine precision and speed. Designed for processing medium-hard, impact-resistant, and friable materials, these machines are engineered for excellence. Material enters the system through the center of a vertically anchored grinding disc, harmoniously aligned with a high-speed rotating counterpart. The centrifugal motion propels the material through the grinding zone, resulting in a finely powdered product. This is efficiently gathered via a blower and cyclone system. Customizable for specific needs, machines come fitted with either one-piece grinding discs or modular grinding segments, depending on your unique application requirements. Technical Features: 1. Experience innovation with our newly designed disc, crafted for exceptional quality and unmatched resistance. Its lifespan is twice that of conventional grinding discs, promising long-lasting reliability.
2. Our state-of-the-art bearings, engineered for high rotation speeds, complement a single drive motor, maximizing grinding efficiency and reducing operational time and complexity.
3. Enjoy the simplicity of installation and maintenance; a quick opening of the door allows for effortless cleaning, making upkeep stress-free.
4. The entire milling process is expertly sealed, ensuring zero dust escape for a cleaner, safer working environment.
5. Effortlessly manage production with our fully automated design, which handles feeding, discharging, and sorting autonomously.
6. Fine-tuning the grinding gap is remarkably straightforward; simply utilize the feeler gauge and adjust bolts for precise control.
7. Our machine integrates a dual cooling system, utilizing both water and wind for optimal temperature regulation.
8. Tailor your setup with an extensive array of optional accessories, allowing you to craft professional solutions aligning with your budget and specific processing demands.
Advantages: Effortlessly fine-tune with simple cutting gap adjustments.
Flexibility with a choice between discs or segments for customized needs.
Achieve high throughput with remarkably low drive power.
Our innovative design promises unprecedented efficiency and performance.
Equip with a plethora of accessories for a fully personalized experience.
Easily manage and control temperature for optimal operation.

---
