| Max. swing over bed | 320mm |
| Max. swing over cross slide | 210mm |
| Max.machining length | 600mm |
| Spindle taper | MT5 |
| Spindle bore | 38mm |
| Max. travel of tail-stock sleeve | 70mm |
| Taper of tail-stock | MT3 |
| Middle carriage travel | 170mm |
| Small carriage travel | 100mm |
| Metric thread/Grade | 0.5~4mm/17 |
| Inch thread/Grade | 9~40T.P.I/20 |
| Transverse feed | 0.025~0.34mm/r |
| Longitudinal feed | 0.135~1.80mm/r |
| Spindle speed range/Grade | 60~1600r/min(12) |
| Motor power | 1100W |
| Net weight/gross weight | 240KG/260KG |
| Overall dimensions | 1220x660x450mm |
| Packing Size | 1400x770x750mm |
