| US$3,988.00-15,898.00 | 1 Set (MOQ) |
| Specification | Units | XK6040 | XK6032 |
| Table size | mm | 1700*400 | 1600*320 |
| T slots(N/W/D) | mm | 3/18/90 | 3/18/70 |
| Longitudinal travel | mm | 1000 | 900 |
| Cross travel | mm | 350 | 310 |
| Vertical travel | mm | 360 | 410 |
| Table longitudinal feed(auto) | mm/min | 6-3200 | |
| Table cross feed(auto) | mm/min | 6-3200 | |
| Table vertical feed(auto) | mm/min | 3-1600 | |
| Distance between spindle and table surface | mm | 20-380 | 55-465 |
| Distance from spindle axis to arm | mm | 155 | |
| Spindle hole taper | - | ISO 50(7:24) | |
| Spindle speed step | step | 18 | |
| Spindle speed range | r/min | 30-1500 | |
| Power of spindle motor | kw | 11 | 7.5 |
| Torque of X/Y/Z axis AC servo motor | N.m | 15/15/23 | 10/10/18 |
| Overall size | mm | 2550*2160*1800 | 2040*1800*1800 |
| Net weight | kg | 3650 | 2650 |
