Brick Molding Made in China Qunfeng Forming Block Making Machine

Product Description

Product Description

Features
This machine is an economical machine with the feature of compact structure, easy to operate and maintain ,small investment quick returns and it is suitable for those investors who are in small or medium scale to equip this simple automatic production line.
1) Introduce frequency converter, saves the power.
2) All the action is controlled by high-low speed, which can improve the working speed of equipment, and reduce the impact to equipment, lifespan of machine is greatly improved .
3) The vibration system adopts double - motor vibration, compression molding ,Synchronous demoulding ,with high production efficiency and short cycle time. The motor operating speed can be adjusted for different raw materials to get good vibration.
4) Aggregate feeding system adopts rotary raking cart, fast feeding with high quality, easy for changing the rake and maintenance
5) Compact structure, easy operation and maintenance, solid and reliable, suitable for customers who starts the investment.
Technical data

Dimension	3270×1850×3200mm
Rating pressure	21MPa
Vibration	Table vibration
Vibration frequency	1500-4100 r/min
Pallet size	850×680 mm
Cycle time	12-25 sec.
Power	37.5 kW
