| US$100.00-1,000.00 | 1 KM (MOQ) |
| Item | Parameter | ||||||
| Fiber Unit | Tight tube: PBT (Polybutylece terephthalate) Fiber: G.652 Single mode fiber or customized Fiber Quantity: Customized Filling (Fiber jelly): Thixotropy jelly | ||||||
| Fiber | G.652D or customized | ||||||
| Fiber unit | 4/8/12 | 24 | 48 | 72 | 96 | 144 | |
| Cable Standard Out-Diameter (mm) ±0.25 | 12.5 | 12.5 | 13 | 13.3 | 13.6 | 13.8 | |
| Span (M) | 100 | ||||||
| Cable Standard Weight (Kg/Km) | 125 | 125 | 132 | 137 | 145 | 147 | |
| RTS (KN) | 11 | 11 | 15 | 20 | 24 | 30 | |
| MAT (KN) | 4.4 | 4.4 | 6 | 8 | 10 | 12 | |
| EDS (KN) | 2.75 | 2.75 | 3.25 | 5 | 6 | 7.5 | |
| Min-bending Radius (mm) | Short Term | 20D | |||||
| Long Term | 10D | ||||||
| Suiting Line Voltage Class (KV) | ≤35 | ||||||
| Suiting Meteorological Condition | Max wind speed: 58m/s; Max icing: Customized | ||||||
| Operation Temperature (°C) | Working & Storage | -40-+80 | |||||
| Installation | -10-+80 | ||||||
| Fibre Attenuation Coefficient In Cable (dB/KM) | 1310nm | ≤0.36 | |||||
| 1550nm | ≤0.22 | ||||||
| Color | Blue, Orange, Green, Brown, Gray, White, Red, Black, Yellow, Purple, Pink, Light Green | ||||||
