| US$3,023.00 | 1 Piece (MOQ) |
max swing over bed | 320mm |
| max swing over cross slide | 198mm |
| max swing over gap | 450mm |
| distance between centers | 800/1000mm |
| spindle bore | 38mm |
| taper of spindle bore | MT5 |
| range of spindle speed | 70-2000rpm |
| stations of tool carrier | 4 |
| range of longitudinal feeds | 0.079-1.291mm/rev |
| range of cross feeds | 0.017-0.276mm/rev |
| range of metric threads | 0.4-7mm |
| range of inch threads | 4-60TPI |
| cross slide travel | 160mm |
| top slide travel | 80mm |
| swiveling angle of turret | 45degree |
| max travel of tailstock quill | 100mm |
| taper of tailstock bore | MT3 |
| motor power | 1.5KW |
| packing size | 1680/1850x750x1400mm |
| net weight | 660/550kgs |
