8up Online CTP with Multi Cassette Autoloader

Product Description

8Up Online CTP with Multi Cassette Autoloader
Model: T-800Q (Multi-cassette)
--- Super Fast, Supreme Imaging Quality, Full Automation(Inline punch built in)
Details

Automatic plate feeding cassette Single cassette autoloader takes 100 plates and multi-cassette autoloader(TBA) takes 400 plates in total.
Specification

T-800Q(F, V, X) Machines
Model	T-800F	T-800V	T-800X
Exposing Method	External Drum
Imaging System	825nm laser
Throughput	35plates/hour	45plates/hour	55plates/hour
	1030mm x 800mm, 2400dpi
Plate Sizes	Max. 1163mm x 940mm; Min. 400mm x 300mm
Plate Thickness	0.15mm, 0.30mm
Resolution	Standard: dual resolutions 2400dpi and 1200dpi or optional 2540dpi and 1270dpi. Variable high resolution option: maximum up to 10000dpi at fast scan direction.
Repeatability	0.01mm
Interface	Optical Fiber(Fiberway)
Punching System	Optional: internal punching(maximum four sets of plate holes)
Net Weight	CTP: 1200kg, Simplified Autoloader: 200KG, Multi-cassette Autoloader: 570KG
Machine Size(WxLxH)mm	1900 x 2370 x 1320
Power Supply	CTP(Single phase: 220V, Max. power(Peak Value): 4KW) Simplified Autoloader(Single phase: 220V; Max. power(Peak Value): 900W) Multi-cassette Autoloader(Single phase: 220V; Max. power(Peak Value): 1100W)
Environment	Recommended temperature: 21-25ºC, Relative humidity: 40-70%

T-800 Q(F, V, X) Machines
Model
T-800F; T-800V; T-800X
Exposing Method
External Drum
Imaging System
825nm laser
Throughput
35plates/hour; 45plates/hour; 55plates/hour, 1030mm x 800mm, 2400dpi
Plate Sizes
Max. 1163mm x 940mm; Min. 400mm x 300mm
Plate Thickness
0.15mm, 0.30mm
Resolution
Standard: dual resolutions 2400dpi and 1200dpi or optional 2540dpi and 1270dpi.
Variable high resolution option: maximum up to 10000dpi at fast scan direction.
Repeatability
0.01mm
Interface Optical
Fiber(Fiberway)
Punching System
Optional: internal punching(maximum four sets of plate holes)
Net Weight
CTP: 1200kg, Simplified Autoloader: 200KG, Multi-cassette Autoloader: 570KG
Machine Size(WxLxH)mm
1900 x 2370 x 1320
Power Supply
CTP(Single phase: 220V, Max. power(Peak Value): 4KW)
Simplified Autoloader(Single phase: 220V; Max. power(Peak Value): 900W)
Multi-cassette Autoloader(Single phase: 220V; Max. power(Peak Value): 1100W)
Environment
Recommended temperature: 21-25ºC, Relative humidity: 40-70%
Producing and Packaging

From producing to delivery, we make every details very carefully to guarantee the good product quality and service to customers.
Certifications

FAQ

1) What are your main products ? A: Our main products are the Prepress CTP System(4up and 8up Online/Offline Thermal CTP, CTCP, VLF CTP and CTCP, Flexo CTP, Processor) and Post Press Packing Equipments(Laminating Machine, Foil Stamping and Die Cutting Machine, Paper Box Window Patching Machine, Book Binding Machine and so on) and the Printing Consumables(Offset Printing Plates, Inks, Printing Blankets, Plate Dot Densimeter). Our partners in USA, Canada, Mexico, Colombia, Turkey, Hungary, South Africa and so on are very pleased with our technician support service and product performance. You can get the Pre-press and Post Press equipments and consumables all in one and no worry about the after-sales service from our company.

2) Where is your factory ? A: Our CTP machine factory is located in Hangzhou city, which is about 1.5 hours by train from Shanghai. You are warmly welcome to visit our factory!

3) What is your warranty for the CTPs ? A: Three years' Laser Head and main spare parts for the CTPs, one year for the Processor.

4) What is the Lead Time ? A: Usually 20-30 days, and we will try our best to meet your demands.

5) Can you also supply the Workflow and RIP ? A: Yes, we can provide the Workflow Brain New and RIP Compose V9. Machine price does not include software.

6) What about the Installation and After-sales technician support ? A: Our engineer can go to help the installation and provide the necessary training. The buyer should take the round air plane tickets, service charge and the local accommodation cost. Any problems or questions, we will be at your disposal 7x24 hours. Among our large amount of CTP many end users(printers) who have purchased the CTP products from EcooGraphix China directly and EcooGraphix technical service team support these installations remotely with regular on site visits. These end users printers all run the CTP systems with full satisfaction due to our robust quality, seamless remote service, thorough training and maintenance. If you are a printer who is considering purchasing directly from EcooGraphix China, there is no hassle on installations, training and after sales service. We guarantee your satisfaction.

---
