Yyn0 Dyn11 500kVA Voltage Oil Immersed Electrical Distribution Three Phase CE IEC

Product Description

Product Description

Technical Parameters

Rated capacity (kVA)	High voltage(KV)	Voltage Combination		Connective group label	No-load loss(KW)	Load loss (KW)	No-load current(%)	Short circuit impedance (%)	Weight (KG)
		High pressure tap range	Low voltage(KV)						Weight of oil	Total weight
30	20/10	±5*2.5% ±2*2.5%	0.4	Dyn11	0.09	0.66	2.1	5.5	180	420
50					0.13	0.96	2.0		150	495
63					0.15	1.145	1.9		170	560
80					0.18	1.37	1.8		190	635
100					0.2	1.65	1.6		215	710
125					0.24	1.98	1.5		250	840
160					0.29	2.42	1.4		285	945
200					0.33	2.86	1.3		340	1125
250					0.4	3.35	1.2		390	1295
315					0.48	4.01	1.1		445	1475
400					0.57	4.73	1.0		515	1712
500					0.68	5.66	1.0	6.0	460	1995
630					0.81	6.82	0.9		565	2450
800					0.98	8.25	0.9		635	2765
1000					1.15	11.33	0.7		840	3650
1250					1.35	13.2	0.7		970	4220
1600					1.63	15.95	0.6		1105	4800
2000					1.95	19.14	0.6		1205	5240
2500					2.34	22.22	0.5		1300	5650

Packaging & Shipping
Company Profile
Certifications

Global Exhibition
Workshop

FAQ
1.Are you a trading company or a manufacturer?
We are a professional factory with 10 years of experience in the field of high and low voltage switch gear and substation. Transformers, cables, distribution boxes and various electrical equipment, such as vacuum circuit breakers, load breaking switches, etc. Our factory is an excellent supplier of the State Grid Corporation of China. 2.Do you accept custom service? We provide OEM/ODM services, according to your drawings and parameters, our professional technical and national team can provide satisfactory solutions. 3.What is your minimum order quantity? Our minimum order quantity is 1 piece. 4.What is your lead time? It depends on your product requirements and quantity. It usually takes 5-15 working days.
5.How do you solve quality problems? Please provide detailed photos of the quality problem. Our technical and quality inspection departments have done a good analysis. We'll come up with a satisfactory solution within two days. 6.What are your terms of payment? T/T payment can negotiate the balance of deposit.Western Union, letter of credit is also acceptable.

---
