0.9 Degree 3D Printer Bipolar NEMA 17 Hybrid Stepper Motor

US$6.98

100-999 Pieces

US$6.08

1,000+ Pieces

Basic Info.

Model NO.

17HM

Function

Driving

Number of Poles

Type

Magnetic-Electric

Brand

Leison Motor

Step Angle

0.9 Degree

Hold Torque

up to 42n.Cm

Phase

2 Phase

Current

0.4-2.5A

Motor Body Length

28mm, 34mm, 40mm, 48mm

Shaft

D-Cut or Round, Customized Shaft Length

Connectors

Can with Connectors, 4 or 6 Lead Wires

Customized

Shaft, Wire, Connector

Transport Package

60PCS/Ctns Carton Size Is 37*31*22cm

Specification

CE, ROHS

Trademark

universal

Origin

Zhejiang

HS Code

8501109990

Production Capacity

100, 000PCS/Year

Product Description

1. 0.9 Degree 3D Printer Bipolar NEMA 17 Hybrid Stepper Motor Specification:
Step Angle Accuracy: ± 5% full step, no load
Ambient Temperature: -20° - +50°
Insulation Resitance: 100M Ω Min 500V DC
Dielectric Srength: 500V AC for one mintue
Resistance Accuracy: ± 10%
Temperature Rise: 80° Max.
Packaging Detail: Foam inner, Papers Carton Outside, 60PCS/CTNS Carton size is 37*31*22cm
Dimension And Data sheet
:

Series Model	Step Angle (° )	Motor Length (mm)	Rated Current (A)	Phase Resistance ( Ω )	Phase Inductance (mH)	Holding Torque (N. cm Min)	Detent Torque (N. cm Max)	Rotor Inertia (g. cm 2 )	Lead Wire (No. )	Motor Weight (g)
17HM2408	0.9	28	0.6	9	9	10	0.9	20	4	130
17HM3401	0.9	34	1.3	2.4	3.6	24	1.2	34	4	220
17HM3410	0.9	34	1.7	1.2	2.2	24	1.2	34	4	220
17HM3430	0.9	34	0.4	30	45	24	1.2	34	4	220
17HM3630	0.9	34	0.4	30	22	20	1.2	34	6	220
17HM3616	0.9	34	0.16	75	54	12	1.2	34	6	220
17HM4401	0.9	40	1.7	1.5	3.8	36	1.8	54	4	280
17HM4402	0.9	40	1.3	2.5	6.2	36	1.8	54	4	280
17HM4602	0.9	40	1.2	3.2	3.8	26	1.8	54	6	280
17HM4630	0.9	40	0.4	30	34	26	1.8	54	6	280
17HM8401	0.9	48	1.7	1.8	4.0	42	2.2	68	4	350
17HM8402	0.9	48	1.3	3.0	7.0	36	2.2	68	4	350
17HM8403	0.9	48	2.3	1.2	2.0	42	2.2	68	4	350

Stepper Motor Packing:
