Fold Wing Heavy Duty Disc Harrow

Negotiable 1 Piece (MOQ)

Basic Info.

Model NO.

1BZDZ-4.4

Farming Policy

Dry Cultivating Machinery

Power Source

Tractor

Operation

Soil Preparation Machinery, Movable Operation

Traction Type

Traction

Drive Type

Trailed

Arbor Configuration

Vertical Shaft

Color

Green/Yellow/Blue

Model

1bzdz-4.4

Weight

3100

Working Width

4.4

Working Depth

Blade Spacing

230

No of Disc

Dia.of Disc

660

Productivity

Linkage

Trailed

Transport Package

Iron Frame Box

Specification

CE, RoHS, SGS, GMP

Trademark

DADI

Origin

Shandong Yucheng

HS Code

8433110000

Production Capacity

10000PC/Year

Product Description

1BZDZ series wing-folded heavy-duty disc harrow are mainly used for cleaning away stuble of plants before tillage,or crushing clods after tillage on uncultivated land and in sticky heavy clay soil fields,they can also be used as a plough for primary tillage in dry culdtivated fields. The series produced are all fitted with hydraulic rubber wheel for transportation.It is easy to be transported and change direction on the edge of fields.
Specifications:

Model	Unit	1BZDZ-4.4	1BZDZ-4.8	1BZDZ-5.3
Overall dimension	cm	580x450x150	580x495x150	580x540x150
Weight	kg	3100-3150	3250-3300	3400-3450
Working width	m	4.4	4.8	5.3
Working depth	cm	20
Blade spacing	mm	230
No of disc	pc	40	44	48
Dia.of disc	mm	660
Transport clearance	mm	>260
Productivity	ha/h	4.4	4.8	5.3
Matched power	kw	105-110	115-120	125-130
Linkage		Trailed
