Product Details
Product Description
Product Description
Features
u Powerful functions, covering all the existing test methods for the filter integrity testing;
u The first domestic implementation of integrity testing for the ultrafiltration system;
u Scientific authority management design, password, permissions, authority grading, electronic signature, etc., in full compliance with FDA 21 CFR PART 11 requirements;
u It can create120 groups of reservation solution, so the instrument is more simplistic and intelligent;
u With rich data interface, the instrument not only includes the standard configuration of digital and analog interface (RS232/USB), but also can customize a variety of industrial bus and simulation control port according to customer's need, in preparation for the intelligent system upgrade, such as the complete set of online automatic sterilization control system;
u Independent research and development team can carry out the design of specific solutions according to the needs of customers; Many years of field experience and strong professional services can not only ensure that the customers use the instrument at ease, but also can provide the technical support for the design and configuration of the filter system of the customers;
Parameters:
Power Supply
| 100 – 260 VAC, 50HZ, 120W Spare battery（Selection）
|
Operation Pressure
| 100-10000 mbar (145psi) ;
|
Unit
| mbar
|
Operation Condition
| Ambient Temperature：+5℃ ~ +40℃；Relative Humidity：10-80%
|
Dimension（mm）
| 455（Depth）*300（Width）*210（Height1）
|
Function
| Manual Bubble point Test；Basic Bubble Point Test；Extensive Bubble Point Test； Pressure Holding Test；Diffusion FLow Test；Water Immersion Test；Ultrafitration Membrane Test
|
Test Accuracy
| Upstream Volume Test：≤± 4%；Bubble Point Test：≤± 50mbar ；Diffusion Flow Test：≤± 4% ；Water Immersion：≤± 0.01ml
|
Test Scope
| BP：100-8000mbar DF：1-600ml/min WI：0.01-100ml/min
|
Applied Range
| Symmetric and asymmetric membrane test, needle filter, filter bag, flat filter, filter cartridge (big filter volume ), ultrafiltration membrane, ultrafiltration column, a variety of irregular filters
|
Authority Management
| User Name and Password to Login ,electronic signature to meeting the FDA 21CFR PART 11requirements Audit trail (customization)
|
Reservation Solution
| 120 sets
|
Print Function
| Built-in printer；
|
Historical Records
| More than1 5000 sets unlimited sets records
|
Records Copy
| Support USB disk to export （Include test curve）
|
Display Screen
| 7 inch, color touch screen
|
Serial Connection
| RS232/USB
|
Language
| Chinese/English
|
Work Mode
| Online/Offline
|
Other functions
| One/two-dimension cods ,Scanning gun;Lithium battery（customization)
|
Applicable Environment
| Above B level
|
Weight
| 8KG
|
>>
