Product Description★ User friendly dialog interactive helps operations like Calibration, making curves, etc.★ All tools you need: DAC, AVG, TCG,color Bscan, AWS, etc.★ Pulse Repeatition Frequency: 10-3000Hz precise adjust, high speed scan, no miss out.★ High Signal to noise ratio, clear and stable echo, anti-noise design, perfect for tough working conditions.★ 12-digit AD, high speed sampling leads to better echo diagram with all details. Sensitive and can detect even tiny flaws.★ Can use probe frequency 25M perfectly . ★ High speed real-time flaw detection video recording. Unlimited USB data storage.★ Blue tooth connection to mobile device to generate and print detection reports on-site. ★ IP65 standard. Alloy + Silica gel case, water and dust proof, solid and lasts forever. Damping support makes it stands in any angle.★ Battery lasts 15 hours for one charge. Each battery has own charging control so with two batteries it can work around the clock.SpecificationTypeYFD-500 Ultrasonic flaw detectorRange0-15000 mm ,at steel velocityMaterial Velocity00～20000 m/sPulse Repetition Frequency10-3000HzDynamic range≥38dBResolving Power>40dB (5P14)Sensitivity Leavings>68dBReject (suppression)0 to 80% full screen heightTest ModesPulse echo, dual element and thru-transmissionProbe TypesSingle Straight, Single Angle,Daul Straight, Daul Anlge,Thrugh,Creeping,SurfaceGate MonitorsTwo independent gates controllable over entire sweep rangePower RequirementsAC Mains 100-240 VAC, 50-60 HzDisplay Delay-20 to 3400 µsProbe Delay/Zero Offset0 to 99.99µsH×W×D(mm)260×175×60 (mm)Weight1.2kgOperating Temperature-10℃ to 50℃Storage Temperature -30℃ to 50℃Pulse Energy70V,100V,200V, 300V, 400V, 500V selectableRectificationPositive half wave, negative half wave, full wave, RF SystemBandwidth (amplifier bandpass )0.2 to 35 MHzGate MonitorsTwo independent gates controllable over entire sweep rangeSensitivity120 dB max in selectable resolution 0.1, 1.0, 2.0, 6.0 dB.FeaturesFunctionsAutomated display precise flaw location(Depth d、level p、distance s、amplitude、sz dB、ф). Flaw sizing: Automatic flaw sizing using AVG or DAC/TCG, speeds reporting of defect acceptance or rejection. Automated calibration of transducer Zero-point, Angles, Front edge and material Velocity . ( V2 and two hole ) Convenient to make and use DAC/TCG and AVG to evaluate the echo, the curve can be modified and compensated. Connectting U-Disk，the unit can get unlimited memory. Automated make video of test process and play; use upan，the length of video is unlimited. Color Bscan. There are 17 standards of in the unit. Blue tooth connection to mobile device to generate and print detection reports on-site. AWS D1.1. Curved Surface Correction feature. Crack Height Measure function. Magnify gate：spreading of the gate range over the entire screen width. Auto-gain function. Envelope: Simultaneous display of live A-scan at 70 Hz update rate and envelope of A-scan display. Peak Hold: Compare frozen peak waveforms to live A-Scans to easily interpret test results. Scan Freeze：Display freeze holds waveform and sound path data. Alarm：Beep and LED. Real Time Clock. Fill echo. Capture mark. Echo color within the Gate.Base Instrument PackPacking&DeliveryBase Instrument PackagePortable Ultrasonic Flaw Detector Straight Beam Transducer (2.5 MHz, Φ20) Angle Beam Transducer (4 MHz, 8 mm×9 mm, 60°) Interconnect Cable for the transducer (Q9-C5，or optional C9- C5) Rechargeable Li-Ion Battery Package, 8 amp hour Power supply/charger unit Operating Manual in English App Software StrapRelated productsOur CompanyDalian Taijia Technology Co.,Ltd is a high technology company which specializes in supplying and supporting of ultrasonic measurement equipment. prime products include ultrasonic transit-time flow meter, ultrasonic level meter, ultrasonic thickness meter etc. Our products are widely used in water supply and drainage water, petroleum and chemicals, food and pharmaceutical.We have sold product in more than 30 countries, such as America. Italy. India. Korea. Germany. Canada. Australia etc.We thank you for visiting our Web Site and look forward to the opportunity of being of service to you.
>>
