| AC/DC V | |
| Range | AC: 6.000/60.00/600.0V DC: 600.0mV/6.000/60.00/600.0V |
| Accuracy | AC: 1.5%rdg±5dgt at 45 to 400Hz DC: 1.0%rdg±3dgt |
| AC/DC A | |
| Range | AC: 60.00/120.0A DC: 60.00/120.0A |
| Accuracy | AC: 2.0%rdg±5dgt at 45 to 65Hz) DC: 2.0%rdg±8dgt at 60A; 2.0%rdg±5dgt at 120A |
| Frequency (AC/DC A) | |
| Range | AC: 100/400Hz DC: 100/1000Hz/10/100/300.0kHz |
| Accuracy | AC: 0.2%rdg±2dgt at 100Hz; 0.1%rdg±1dgt at 400Hz DC: 0.2%rdg±2dgt at 100Hz; 0.1%rdg±1dgt at 1000Hz/10/100/300.0kHz |
| Input Sensitivity | |
| Current | More than 6A |
| Voltage | -10kHz: More than 6V 10k to 300kHz: More than 20V |
| General Specifications | |
| Continuity Bbuzzer | Buzzer sounds below 3525 |
| Diode Test | 2V3.0% rdg±5dgt |
| Open-Loop Voltage | approx. 2.7V |
| Capacitance | 400.0nF / 4.000 / 40.00F Accuracy: 2.5% rdg±10dgt |
| Conductor Size | 12mm max. |
| Withstand Voltage | 3540V AC for 5 seconds |
| Applicable Standards | IEC 61010-1 CAT III 300V, CAT II 600V Pollution degree 2 IEC 61010-031 IEC 61010-2-032 IEC 61326 |
| Continuous Measuring Time | DCV: approx. 150hours ACA: approx. 25hours (Auto power save: approx. 15 minutes) |
| Power Source | 2 x 1.5V R03 Battery |
| Dimensions | 128 x 92 x 27 mm |
| Weight | Approx. 220 g (Including Batteries) |
