Mpl-B540K-Sj72AA MP-Series Low Inertia Small Frame Brushless Servo Motor

Product Description

Kinetix MP Servo Motors The MPL-B540K-SJ72AA AC motor comes with a RPM rating of 4000 RPM. Also, this high-torque motor has a shaft key, but no shaft seal on the motor. In addition, this low inertia smart servo has a single turn feedback. This MPL servo can be connected by circular DIN (right angle) connectors that are built onto this low rotor motor. This AC synchronous servo motor is a 165 millimeter frame and comes with no brake included.
Part Number/Catalog No. Series Series Type Voltage Class Frame Size Magnetic Stack Length Rated Speed Feedback Shaft Key/Seal Connectors Brake Mounting Flange Factory Designated Options

MPL-B540K-SJ72AA

Premium permanent magnet rotary servo motor

Low inertia

400V AC

165 mm

4 in.

4000 rpm

Single-turn high-resolution encoder

Shaft key/no shaft seal

Circular DIN, right angle, 180 degrees rotatable

No brake

IEC metric

Standard

---
