Basic Info.
Automatic Grade
Automatic
Certification
GS, CE, RoHS, ISO 9001
Dimension (Lxwxh)
6400*2270*2340mm
Transport Package
Nude Packing
Production Capacity
500/Month
Product Description
Horizontal Directional Drill rig XZ180 drilling machine HDD machine
1. Pullback/thrusting: 180/180KN. M
2. Engine: 97 kw CUMMIS
3. Spindle torque: 6000N. M
4. Backreaming diameter: 600mm
Dongfeng Cummins (97KW) engine, 180kN of push-pull, 6000N. M of Max. Spindle torque, motor dual speed chain push-pull system, self-propelled rubber tracks chassis, automatic loading and unloading drill rod device, rotatable control board, patent technology for floating vice, and onboard high-capacity mud pump (250L/min).
Model XZ180
| Engine | | CUMMINS |
| Rated power | kW | 97 |
| Max.pullback/thrusting | kN | 180/180 |
| Spindle torque(max) | N.m | 6000 |
| Spindle speed | r/min | 0-140 |
| Backreaming diameter | mm | Ø600 |
| Tubing length(single) | m | 3 |
| Tubing diameter | mm | Ø60 |
| Entry angle | ° | 10-22 |
| Mud flow rate(max) | L/min | 250 |
| Mud pressure (max) | bar | 80 |
| Overall weight | kg | 10000 |
| DIMENSION (LxWxH) | mm | 6400×2270×2340 |
We supply all kinds of Machinery & Equipment of most Chinese big brands like LIUGONG, FOTON , ZOOMLION, SINOTRUK, SHANTUI etc to global market with reasonable
price and best service. Most of products are meet with ISO,CE,EPA,GOST standards.
Our advantages are as following:
1. Professionally export construction machinery and spare parts for more than 12 years to over a hundred countries.
2. Experienced in customs clearance in different ports(countries). Clients type has big contractors, tender, private,rental companies, construction companies etc.
3. Quick delivery time and thoughtful services.
1) ALL kinds of trucks.
(Dump truck, mining dump truck, tractor truck, truck trailer ,towing truck , water tank truck, concrete mixer truck, oil tank truck, garbage truck, cargo truck, port terminal tractor, refrigerated truck, truck mounted crane, fire truck, suction sewage truck, bus , etc)
2) All kinds of construction machinery.
(Wheel loader, excavator, folklift, cranes, paver, road roller etc.)
3) All machines spare parts.
Please contact us freely to get best price and service.
>>
