Rubber Compression Molding Press Xlb-Dq 2500*2500mm

Product Description

Application:
The machine applies to vulcanizing various kinds of rubber and plastic model products as well as non-model products.
Structure:
The machine is frame structure with below pressing form (upwards). Under the hydraulic pressure, the piston plunger ascends to make hot plate close for getting pressure, while the piston plunger descends (namely hot plate turning on) by deadweight of hot plate, platform and piston plunger to drive working fluid to fuel reserve tank to achieve the aim of descending (namely turning on).
Feature:
1. The material of the piston is LT-P chilled cast iron, the surface is chilled cast iron of vanadium and titanium alloy hard and wearable. It is burnished and polishing by manpower. The hard surface depth can reach to 0.5-0.7mm.
The cylinder mateerial is QT500-7 ductile cast rion and the inside surface is high pressure and nitroger treatment, the surface is burnished and polishing by manpower too. The hard surface depth can reach to0.7-0.9mm.
The set of hydraulic cylinder contain pistin, cylinder, gland ring and the flange. The flange press the gland in order to pevent spillage oil. The material of the gland rig(XY) is oil resistance rubber.
The hydraulic system are fond and machining by ourself.
2. The electricit system we can useMITSUBISHI, DELTA, SCHNEIDER, Siemens etc. You can choose option what kind brand that you want
3. The hydraulic contain three sets low-prssure motor pump and one set high pressure motor pump.
You can also appointment brand of the motor and pump you want. Our engineer can redesign it according to you specific demand.
Technical Parameter:

Type	XLB-DQ1200× 1200× 2	XLB-DQ1300× 2000× 1	XLB-Q1200× 2500× 1	XLB-Q1500× 2000× 1	XLB-Q2000× 3000× 1	XLB-Q1400× 5700× 1
Total pressure(MN)	315t	560t	750t	1000t	1800t	2800t
Platen size(mm)	1200× 1200	1300× 2000	1200× 2500	1500× 2500	2000× 3000	1400× 5700
Daylight (mm)	200	400	400	400	400	400
No of Daylights	2	1	1	1	1	1
Piston stroke(mm)	400	400	400	400	400	400
Plate Unit Area pressure(Kg/cm2)	22	21.5	25	33.5	30	35
Main motor power(KW)	3	8	9.5	11	26	43.5
Overall dimension(L× W× H) (mm)	1685× 1320× 2450	2000× 1860× 2500	2560× 1700× 2780	2810× 1550× 3325	2900× 3200× 2860	2400× 5800× 3600
Weight(kg)	9500	17000	20000	24000	66000	110000

Machine Overview:

---
