| US$100.00-200.00 | 1 Piece (MOQ) |
| Rated line pull | 4500lbs(2043kg)single line |
| Motor (Series wound) | DC 12V: 3.4hp/2.5kw |
| Gear train | 3 stage planetary gear |
| Gear ratio | 180:1 |
| Clutch | Sliding ring gear |
| Braking action | Automatic in the drum |
| Fairlead | 4-way roller fairlead |
| Wire rope | 7/32"×55.8' (Φ 5.4mm×17m) |
| Drum size | 1.73"×4.86" (44mm×123.5mm) |
| Dimensions | 14.88"×4.44"×4.76" (386mm×113mm×121mm) |
| Bolt pattern | 6.6"×3" (168mm×76.2mm) |
| Net Weight | 30.6lbs (13.9kg) |
| Line speed and motor current (first layer) | ||
| Line pull(Lbs/Kgs) | Line speed(FPM/MPM) | Motor current(Amps) |
| 0/0 | 13.1/4.0 | 30 |
| 1500/681 | 9.8/3 | 75 |
| 2500/1135 | 8.2/2.5 | 105 |
| 3500/2043 | 6.6/2.0 | 135 |
| 4500/2043 | 4.3/1.3 | 185 |
| Line pull and cable capacity | ||
| Layer of cable | Rated line pull per layer (Lbs/Kgs) | Cable capacity per layer (Ft/M) |
| 1 | 4500/2043 | 11.5/3.5 |
| 2 | 3691/1676 | 25.6/7.8 |
| 3 | 3129/1421 | 42.3/12.9 |
| 4 | 2715/1233 | 55.8/17.0 |
