| US$8,300.00 | 1 Piece (MOQ) |
| Features | Applications |
| High Output Power | Coherent Detection System |
| Low Noise Figure | Coherent Combining |
| Turn--Key System | Atom Cooling&Trapping |
| All PM Fiber Structure,High Polarization Extinction Ratio | Optical Fiber Sensing System |
| High Stability&Reliability | High Efficiency Second Harmonic Generation |
| Parameters | Unit | Specification | ||
| Min. | Typ. | Max. | ||
| Part no. | ZG-Tm-2000-B-SF-LP | |||
| Operating wavelength range | nm | 1900 | -- | 2200 |
| Output power | W | 0.1 | -- | 2 |
| Input isolation degree | dB | 35 | -- | -- |
| Output isolation degree | dB | 35 | -- | -- |
| Working mode | CW | |||
| Output power adjustable range | % | 10 | -- | 100 |
| Output polarization | linear polarization | |||
| Polarization extinction ratio | dB | 20 | 23 | -- |
| Input signal power | mW | 0.1 | -- | 50 |
| Input signal typical line width | kHz | 0.1 | -- | -- |
| Output power stability | % | -- | ±0.5 | ±1 |
| Input fiber | PM1550-XP or PM1950 | |||
| Input fiber connector | FC/APC(other Options) | |||
| Output fiber | PM1950,9/125um NA=0.20 | |||
| Output fiber connector | FC/APC(other Options) | |||
| Operating voltage/current | VAC | 220V / 50-60Hz | ||
| Operating temperature | ºC | 0 | -- | 50 |
| Storage temperature | ºC | -20 | -- | 70 |
| Size | mm | 260×285×115 | ||
| Cooling way | Air cooling | |||
