US$3,999.00-5,999.00
|
32 Sets
(MOQ)
|
Basic Info.
Usage
Cargo, Cargo And Passenger
Transport Package
SKD Standard Exporte
Specification
3400× 1300× 1500mm
Production Capacity
50000units/Year
Product Description
Detailed Photos Product Parameters
| S/C | Item | Technical specification |
| BODY SPECIFICATION |
| 1 | Whole size | 2930mm×1210mm×1830mm |
| 3 | Track width (mm): | 1040mm |
| 4 | Wheelbase (mm): | 2280mm |
| 6 | Tyre size | 145/70 R12 |
| 10 | braking mode | Front manual hydraulic disc brake, rear brake |
| 11 | Front suspension form | One-shaft hydraulic rocking frame damping |
| 12 | Rear suspension form | Double arm automobile hydraulic vibration reduction |
| 13 | Number of passengers | 5 people including the driver |
| ENGINE |
| 1 | Engine displacement | 200CC water cooled |
| 2 | Engine type | vertical |
| 3 | Start mode | Electricity,feet |
| 4 | Maximum power/rotating speed | 10.2kW/7500 r/pm |
| 5 | Maximum Torque /rotating speed | 14.5N·m/5500r/min |
| 6 | Ignition model | CDI |
| 7 | Lubricating model | Pressure plus splash |
| 8 | Clutch type | Wet multichip type |
| 9 | Primary transmission ratio | 4.055 |
| 10 | Transmission ratio | 2.909/1.867/1.389/1.15/0.955 |
| PACKAGING |
| 1 | Transport | By Land/Sea/Other |
| 2 | Port Of Loading | Chongqing/Shanghai/Other ports of china |
| 3 | Package | Protective Packaging |
| 4 | Loading Capacity (SKD) | 32Units in 40"HQ |
| 5 | Delivery Time (from loading port) | 30-36Days after receiving advance payment |
Product Category
Company Profile
FAQ Q: Are you a manufacturer or a trader?
A: We are a manufacturer, focusing on the R&D, production and sales of tricycles.
Q: What is your MOQ?
A: Our MOQ will be one 40HQ container. Depending on the model, the number of tricycles will range from 20 to 50.
Q: Can I buy a sample tricycle first?
A: Sorry, we cannot provide one or several sample tricycles.
Q: Can you customize tricycles?
A: Yes. We have a strong R&D team and can provide in-depth customization according to the actual needs of customers.
