HOT SALE! ISUZU brand double cabs 4*2 LHD120hp diesel 2T cargo truck with crane
HOT SALE! ISUZU brand double cabs 4*2 LHD120hp diesel 2T cargo truck with crane, adopts ISUZU 100P double cabs 4*2 LHD driver cab, ISUZU MSB 5 speed manual gearbox, 3360mm wheelbase, 2t-2.5T front axle/ 4T-4.8T rear axle, 7.00R16 rail tires, 4KH1CN6LB ISUZU 120hp diesel Euro Ⅵ engine, air conditioner + power steering, etc.
The overall dimension(L*W*H)of ISUZU brand 4*2 LHD double cabs 2T cargo truck with crane is 5995×2098×2750,2650,2550(mm); while the cargo box dimension(L*W*H): 2500×2000×400,450,500(mm). Clients choose to install CLW brand/XCMG brand 2T telescopic/knuckle crane boom.
Main technical parameters of ISUZU 2T cargo truck with crane is as below
Product name
| ISUZU brand 4*2 2T telescopic boom mounted on truck for sale
|
Chassis type
| EQ1090SJ8BDE
|
Parameters
| Overall dimension length/width/height (mm)
| 5995×2098×2750,2650,2550
|
Cargo body dimension (L*W*H)(mm)
| 2500×2000×400,450,500
|
GVW(kg)
| 4495 (Kg)
|
Kerb Mass(kg)
| 3500 (Kg)
|
Approach angle/ Departure angle(°)
| 24/15
|
Front suspension/rear suspension(mm)
| 1015/1620
|
Fuel Type
| diesel
|
Max Speed
| 105
|
Engine
| Type
| 4KH1CN6LB
|
Displacement/Power(kw)
| 2999ml/88KW/120hp
|
Manufacturer
| Isuzu
|
Chassis
| Drive Type
| 4×2
|
Wheelbase(mm)
| 3360
|
Tread(front/rear)
| 1377/1425(mm)
|
Transmission
| ISUZU MSB 5 speed manual gearbox
|
Braking system
| Air braking
|
Cab
| Isuzu 100P double cabs driver cab
|
Number of spring axle(front/rear)
| 3/3+2
|
Tire Type
| 700R16* 6+1
|
Air-condition
| Yes
|
Upper part(cargo van and crane boom) main parameters
|
Upper body
| Cargo body dimension
| 2500×2000×400,450,500
|
Material
| Carbon steel
|
Side sheet thickness
| 2mm thickness
|
Bottom sheet thickness
| 2mm thickness
|
Painting
| Upon request
|
Crane boom main parameters
|
Crane boom
| Choose to install CLW brand 2tons telescopic crane boom
|
Rotation
| Full hydraulic, full rotation
|
The color of the whole truck is upon request.
|
If you're interested in our ISUZU brand double cabs 2T cargo truck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: 0086 13329899995.
More pictures of ISUZU double cabs 2T mobile truck with crane is as below.
ISUZU brand double cabs 2T cargo truck with crane for sale
The cargo crane is also called truck mounted crane, crane truck, truck with crane, etc. The truck with crane is mainly used to lift and transport the constuction material, equipment or other large goods by municipal corporation, mining engineering department, plant department,etc
As a professional cargo truck crane supplier in China, we Chengli Special Automobile Co., Ltd. manufacture the crane boom is from 2 ton to 160 ton. The drive type of our truck crane for sale are 4x2, 6x2, 6x4,8x4,etc. The truck mounted crane for sale are telescopic boom truck mounted crane, knuckle boom truck mounted crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc. The crane for truck can be crane, chengli crane, sany crane, unic crane, kanglim crane, etc.
>>
