Industrial Flat Transmission Belt Spindle Tape Grinder
US$200.00
1 Piece
US$100.00
2+ Pieces
Basic Info.
Certification
CE
Condition
New
Customized
Non-Customized
Automatic Grade
Automatic
Structure
Vertical
Power
3.5kw
Voltage
220V/380V
Width
100-600mm
Motor
Yes
Transport Package
Wooden Case
Specification
1500mm
Trademark
Bayrich
Origin
China
HS Code
8477800000
Production Capacity
300PCS/Month
Product Description
Bayrich flat belt grinding machine for endless splice prepare ★Detail: This grinding machine a preparing device for skiving of flat belts up to a width of 400 mm and a thickness of 6 mm. ★Feature: 1.The belt is clamped and stuck on a steel table. This table is adjustable in tilt and is fed under a grinding drum on precise guides. 2.The grinding drum is driven by a powerful three-phase electric motor; feed is by means of a self-contained two-speed electro-hydraulic drive. A nonadjustable fast one for in-feed and an adjustable for slow-working speed. 3.This feed gives smooth automatic and productive operation. 4.No operator intervention is necessary during the skiving process. 5.The result of this operation is a precise skiving, even on the most demanding belt products. 6.This grinding machine especially suitable for preparation of Thermofix joints of power transmission belts in the fabrication workshop in large series.
