| Model:R-I86NLH | |||
| PC | |||
| CPU | Intel Cherrytrail Z8350, 1.44Ghz-1.92GHz | ||
| GPU | Intel® HD Graphics | ||
| RAM | 4GB | ||
| SSD | 64GB, Optional 128G | ||
| G_sensor | Gravity acceleration sensor | ||
| WIFI | WIFI 802.11(a/b/g/n/ac) Frequency 2.4G+5.8G dual band WIFI intel 3165D2WG | ||
| Bluetooth | BT4.2 (BLE) class1 transmission distance: 10m | ||
| 3G | Optional: IC: H350-A30: WCDMA (900/2100MHz), GSM (900/1800MHz), HSDPA 7.2Mbps, HSUPA 5.7Mbps, LGA interface. | ||
| 4G | EC25-EC (Europe) LTE FDD: B1/B3/B7/B8/B20/B28A WCDMA: B1/B8 GSM: B3/B8 Optional: EC25-AU LTE FDD: B1/B2/B3/B4/B5/B7/B8/B28 LTE TDD: B40 WCDMA: B1/B2/B5/B8 GSM: B2/B3/B5/B8 | ||
| GPS | U-blox NEO-7; Capture sensitivity: -160 dBm; Cool Start Time:<50 seconds, Hot start time: | Camera | Front:2.0MP with indicator light, Rear: 5.0MP |
| Speaker | 8Ω/0.8W waterproof BOX speaker*1 | ||
| Mic | Sensitivity:-42db, output impedance 2.2kΩ | ||
| Operation System | windows 10 Smode /Pro | ||
| LCD panel | |||
| Panel size | 8" | ||
| Resolution | 800*1280 IPS LCD | ||
| Aspect ratio | 16:10 | ||
| Brightness (cd/m²) | 450 cd/m2 | ||
| Touch panel | |||
| Touchscreen Type | Multipoints Capacitive, G+G | ||
| Surface Hardness | 7H | ||
| Interface | |||
| USB | 1*USB2.0(Host), 1*micr usb | ||
| Audio Output | 1*3.5mm | ||
| HDMI | 1*HDMI 1.4a Type C | ||
| TF Slot | 1*TF Slot, max 128G | ||
| SIM | 1*SIM | ||
| Power | 1*DC 5V 3A, Optional: Overvoltage protection of circuit, Max DC24V. | ||
| Pogo Pin | 1*12pin Pogo Pin | ||
| Power Supply | |||
| Power Adaptor | AC100V ~ 240V, 50Hz/60Hz, Output DC 5V/3A | ||
| Battery | build in polymer li-ion battery | ||
| Capacity: 3.7V/8500mAh, 4G: 3.7V/7800MAH | |||
| 8Hrs(default 50% volumn, default200 lumens brightness, play 1080P HD video) | |||
| Operating Environment | |||
| IP grade | IP65 waterproof | ||
| Drop Height | 1.22cm composite wood floors, in operation status | ||
| Operate Temperature | -20 °C to 60 °C | ||
| Store Temperature | -30 °C to 70 °C | ||
| Humidity | Humidity: 95% Non-Condensing | ||
| Packing Details | |||
| Net weight | 737g | ||
| Gross weight | 1382g | ||
| Product Dimension | 228*145*16.5mm | ||
| Packing size | 357*186*60mm | ||
| Other | |||
| Warranty | 1 year warranty | ||
| Certificate | CE, FCC, RoHS | ||
| Color | black, silver | ||
| Accessories | Power Adaptor, OTG cable, USB cable | ||
| Module extension (Optional) | |||
| One-dimension barcode | MOTO SE655E100R, optical resolution: 5mil, SCAN Speed: 50 times/s, support code system :UPC/EAN, Bookland EAN ,UCC Coupon Code,ISSN EAN,Code 128,GS1-128,ISBT 128,Code 39,Trioptic Code 39 ,Code 32,Code 93 ,Code 11 | ||
| Two-dimension barcode | MOTO SE4710 Hardware decoder, optical resolution:5mil, scan speed:50times/s, support code system:PDF417, MicroPDF417, Data Matrix, Data Matrix Inverse, Maxicode,QR Code, MicroQR, QR Inverse,Aztec,Aztec Inverses,Han Xin,Han Xin Inverse | ||
| NFC | NXP NFC 13.56MHz support SO/IEC 14443A/14443B/15693/18092/mifare protocol, Card reading distance: 4cm | ||
| Optional Accessories | |||
| Accessories | Docking Charger, Hand-strap, Vehicle Mount, Leather Cover, Back-strap, Shoulder-strap, TP Resist film, 5V3A Car Charge | ||
