Genie® GS™-4655 electric scissor trolley is a sturdy, durable, energy-saving and environmentally friendly device. Equipped with the leading Genie AC electric drive system, it is suitable for indoor and outdoor work sites. The leading working height and load capacity and high-performance AC drive motor can comprehensively improve work efficiency.
The powerful AC electric drive system effectively improves the working performance of the equipment and extends the running time.
25% gradeability and 14° breakover angle, making it easy to climb loading ramps
The platform has a large working space and the extended platform size is 1.22 meters.
User-friendly Smart Link™ dual-zone control system for indoor and outdoor jobsite applications
| Models |
|
| GS4655 |
|
|
| Models |
|
|
| Measurements |
| US |
| Metric |
| Working height max. - indoor |
| 51 ft 9 in |
| 15.95m |
| Working height max. - outdoor |
| 27 ft 6 in |
| 8.55m |
| Platform height max. - indoor |
| 45 ft 9 in |
| 13.95m |
| Platform height max. - outdoor |
| 21 ft 6 in |
| 6.55m |
| Platform height - stowed |
| 5 ft 5 in |
| 1.64m |
| Platform length - outside |
| 9 ft 4 in |
| 2.84m |
| Platform length - outside, extended |
| 13 ft 4 in |
| 4.10m |
| Slide-out platform extension deck - length |
| 4 ft |
| 1.22m |
| Platform width - outside |
| 4 ft 5 in |
| 1.35m |
| Guardrail height |
| 3 ft 7.3 in |
| 1.10m |
| Toeboard height |
| 6 in |
| 15 cm |
| Machine Height - stowed (folding rails) |
| 9 ft 1 in |
| 2.77m |
| Machine Height - stowed (rails lowered) |
| 6 ft 6 in |
| 1.98m |
| Length machine - stowed |
| 10 ft 2 in |
| 3.11m |
| Length machine - stowed, extended |
| 14 ft 2 in |
| 4.33m |
| Width |
| 4 ft 7 in |
| 1.40m |
| Wheelbase |
| 8 ft 1 in |
| 2.47m |
| Ground clearance (center) - pothole guards retracted |
| 5.9 in |
| 15 cm |
| Ground clearance - pothole guards deployed |
| 0.75 in |
| 2 cm |
|
|
|
|
|
| Productivity |
|
|
|
|
| Max. platform occupancy (in/out) |
|
| 3\2 |
|
| Lift capacity |
| 770 lb |
| 350 kg |
| Lift capacity - extension deck extended |
| 300 lb |
| 136 kg |
| Max. platform drive height |
| 45 ft 9 in |
| 13.95m |
| Drive speed - stowed |
| 2.5mph |
| 4.0 km/h |
| Gradeability - stowed |
|
| 25% |
|
| Turning radius - inside/outside |
| 12 in/ 10 ft |
| 31 cm/ 3.05m |
| Lifting speed - raise/lower |
|
| 92/58 sec |
|
| Tilt sensor activation (front to back/side to side) |
|
| 3°/ 1.5° |
|
| Tires - solid non-markin |
| 15 × 5 in |
| 38 × 13 cm |
|
|
|
|
|
| Power |
|
|
|
|
| Power |
|
| 24V DC (4 × 12V 300Ah) |
|
| Hydraulic tank capacity (E-Drive) |
| 7.5 gal |
| 28.4 L |
|
|
|
|
|
| Weight(3) and Floor Loading |
|
|
|
|
| Weight |
| 8,160 lb |
| 3,701 kg |
| Weight max. (adding all possible options) |
| 8,161 lb |
| 3,702 kg |
| Tire load max. |
| 3,682 lb |
| 1,670 kg |
| Tire contact pressure |
| 210 psi |
| 1,451 kPa |
| Occupied floor pressure |
| 205 psf |
| 9.81 kPa |
|
|
|
|
|
| Sound and Vibration Levels |
|
|
|
|
| Sound Pressure level (ground workstation) |
|
| <70 dBA |
|
| Sound Pressure level (platform workstation) |
|
| <71 dBA |
|
| Vibrations |
| <8 ft 2 in/s2 |
| <2.5m/s2 |
