| Inside | 6900X3900X2650(LXWXH) |
| Outside | 7120X5400X3400(LXWXH) |
| Metal base | 0.6mm galvanized sheet,300mm metal base, two rows of gratings ,two outside ramps |
| Wall panels | 60mm thickness by tongue and groove interlock, 12g EPS insulation |
| Main door | Three-fold common door: 3000X2600mm(WXH) with pressure lock |
| Service door | One service door: 2000X800mm(HXW) with pressure lock |
| Lights | Upper inclined lights,8 units,4X36W each |
| Air system | Air intaking: 1X5.5KW turbo fan with CE motor, 20000m3/h |
| Air exhausting: 1X5.5KW turbo fan with CE motor, 20000m3/h |
| Frames by square tubes, double 0.6mm galvanized sheet with rock-wool |
| Ductings: 0.6mm galvanized sheet, manual damper for exhausting |
| By-pass | Electric damper from spraying to baking cycle |
| Heating system | Big heating exchanger by stainless steel, Italian G20 oil burner,18000kcal/h |
| Filter system | Prefilter-----600G ceiling filter----- floor paint-stop filter-----glass-fiber extraction filter |
| Control system | spraying, heating spraying, bake timer, indicator lights, hour timer, over temperature alarm, emergency stop, pressure gauge, Chinese contactor, Chinese temperature controller etc. |
ODDLY company belongs to a large-scale automobile enterprise integrating research and development manufacturing, sales and service. The company was founded in October 2016, with 1 million Yuan registered capital, located nears Shanghai seaport, which provides advantages for Importing and exporting trade of the products. The company currently employs more than 20 people, including 2-3 technical personnel, 3-5 international business persons. Our company is with excellent staff, advanced technology, sophisticated equipment, strict management system. Based on this, the company continuously grow and development. "Cooperation, innovation, win-win situation" is our production spirit and service concept. Over the past years, ODDLY has rapidly emerged with its professionalism and proven technology in the field of automobile. In the process of development, the company continues to exchange and cooperation with a number of domestic scientific research institutions, design and production, maintenance and commissioning capacity rapidly improved, the scale continues to expand. With science and technology for development, and constantly provide users with excellent quality, stable performance, convenient and fast, durable automobile equipment, is our constant pursuit. Our products are with best quality and super technical services, and strive to create a world-renowned brand, so that Chines products will be all over the world. Certifications
