Microcomputer Double Worm Wheel Double Guide Paper Cutting Machine (SQZK1300DW-8)

Product Description

SQZK1300DW-8 Microcomputer double worm wheel double guide paper cutting machine

Model	unit	SQZK1300DW-8
Max cutting width	cm	130
Max cutting length	cm	135
Max cutting height	cm	16.5
Max clamping pressure	N	40000
Cutting speed	Cycles/min	45
Cutting motor power	Kw	4
Sending paper motor power	Kw	0.55
Wind pump motor power	Kw	0.75
Net weight	kg	4600
External dimension(L*W*H)	cm	280×339×174
Packing dimension(L*W*H)	cm	333×157×204

1. Usage: SQZK-DW-8 Microcomputer Paper Cutting Machine is used to cut the printing paper of various kinds, paper products, plastic, thin film, leather, slice of non-ferrous metal, etc.

2. 8inch TFT color LCD : This kind of programmable frequency microcomputer adopts 8 inch color LCD. The main computer chip adopts CPU from America AMD Company. It has six languages. Also it has self fault diagnosis function and animation operation mode display. Programming capacity of up to 200 groups, each program group has 999 different position cutting data. The storage memory hours are over300, 000 hours which ensure the reliability of performance. The paper sending motor power controlled by import frequency changer. It matches the high precision paper delivering structure to realize step less speed adjustment. the speed of Paper sending reaches 6-12m/min, and the position accuracy can be 0.05mm.

3.semi-automatic: paper-sending is automatic, but paper-cutting is manual.

4. Double Worm Wheel Device: the Worm wheel system adopts the Germany advanced technology. It pass the patent No:ZL 2007 2 0192036. X. This structure is new in the paper cutting machine market. In china, only our machine's double worm wheel structure passed the patent. This structure pulls the knife seat fall down from double side. In this way, the cutting will have heavier power and more precise.

5. Double Guide Device: the paper pusher adopts double linear guide and roller ball screw. This can prolong the machine use life, and can bear the high speed paper delivering

6. Photo cell: it is equipped with a photo cell safety protection device.

7. Over load protection device; convenient knife changing device.

8. Worktable chrome treatment: the worktable and side board surface are all adopted chrome treatment to improve the precision and quality of the machine.

9. Air ball: air balls are installed in the worktable. The paper sending work will be easy and accurate.

10. Cutting controller: both hands of the user press the cutting button to operate the machine.

11.Electronic knife lock: when the machine is malfunction, the electronic knife lock will lock the knife, and the machine will stop cutting to protect safety.

12. Safety notice & Glass covers: all the safety notice and direction mark is used to cause the safety attention of the user, and do protection and maintenance in time.

13. Main electric device are imported from Germany, French, Japan, etc.
Machine transport and packing
__________________________________________________________________________
1. The packing of small machines is confirm to export wooden case standard, strong and durable. The wooden case's thickness is generally 1 cm.
2. In order to be waterproof, we usually use bubble film to wrap machine.
3. We can handle shipping for customers too.
Our Company:
_____________________________________________________________________

Certificate:
______________________________________________________________________
FAQ:
______________________________________________________________________
Q1: Are you a manufacturer?
Yes, we are specialized manufacturer of hot foil stamping machine and die cutting machine in China over 20 years.
Q2: Do you have stock products to sell?
We manufacture machines in batch. So most of machines have in stock, please check with us before ordering.
Q3: How about installation and training?
Installation and training: If purchaser's engineer travels at own cost to China, free training session. If engineer sent to purchaser's factory, all travel cost paid by purchaser.
Q4: How about warranty?
Warranty period: 12 months from the shipping date of machine. Warranty will be not valid if machine subject to misuse or accidental damage or operator's error. During the valid time, we will supply spare parts. If you have any other questions, pls contact us and we will reply you through product's photos and videos to make every detail clear.
Why choose us?
_____________________________________________________________________
1.Our brand "INNOVO" is well-known in our domestic market and over 80 countries and territories. Europe, South America, Latin America, Southeast Asia, Middle East, Africa etc.
2.Genuine products with excellent quality. Company has always proved the 100% quality.
3.After-sales service and technical assistance: company provides after sales service and technical assistance as per customers' requirement and needs. After-sales service provided engineers available to service machinery overseas.
4.Cost saving: lon-life, shock resistant and high reliability bearings with excellent quality and better performance, resulting in increased cost saving.
5.Less cost of purchase: We are the manufacturer directly.
6.Attendant customers queries promptly.

---
