| US$1,200,000.00-1,300,000.00 | 1 Piece (MOQ) |
Item | Equipment Name | Model | Unit | Qty. | Remark |
| 1 | |||||
| 1.1 | Mast | JJ450/45-K | set | 1 | К,45m,4500KN,24.5m, 25.5m26.5m.7000m (5"),API Spec 4F. K Type Mast, Five Sector,Avaliable height: 45m, max.static load:4500KN, Racking Board Height:24.5m, 25.5m and 26.5m. racking board DP Capacity:7000m(5'' DP), the mast meet API Spec 4F. |
| 1.2 | Crown Block | TC-450 | set | 1 | 4500KN,6,φ1524mm; 1,φ1524mm;4,φ400mm;:38mm(1-1/2″),,,,API Spec 4F. The Crown Block with max.hook load 4500KN, 6 pcs crown block sheaves with dia. φ1524mm, 1 pc fast line sheave with dia. φ1524mm, 4 pcs auxiliary sheaves with dia. φ400mm. Suitable for drilling line with dia. 38mm(1-1/2″). Include crown block floor, equip with lift crane, protection handrail and bumper device. The crown block meet API Spec 4F. |
| 1.3 | Racking Board | set | 1 | 24.5m,25.5m26.5m,.2.0m. The racking board has three avaliable height:24.5m,25.5m and 26.5m that can be adjusted. Equip with 2.0m height windwall that made of galvanized steel plate. | |
| 1.4 | () Air Winch on Racking Board(used for lift the DC and DP) | JQH-5/48 | set | 1 | -5KN,-0.8MPa. Lift Weight-5KN,Working Pressure-0.8Mpa |
| 1.5 | Deadline Anchor | JZG41 | set | 1 | -410KN, . Max.working load-410KN, include weight indicator and recorder. |
| 1.6 | Escape Device on Racking Board | set | 1 | ||
| 1.7 | Ladder Climping Assistor Device | set | 1 | ||
| 1.8 | Tong Balance Weight | set | 2 | ||
| 1.9 | Wireline Stabilizer | .pcs | 2 | ||
| 1.10 | Rope Guide | pcs | 1 | ||
| 1.11 | Mast Delivery and Install Rack | set | 1 | ||
| 1.12 | Hoisting Line of Mast and Substructure | set | 1 | :71mm, 61.3m43mm, 41.5m2. Totally 4 pcs lines, 2 pcs line with dia.71mm and length 61.3m, 2 pcs line with dia.43mm and length 41.5m. | |
| 1.13 | , Ladder, Handrail and Walkway | set | 1 | 1200mm. The height of handrazil is 1200mm. | |
| 1.14 | Fall Arrestor | set | 1 | ||
| 2 | |||||
| 2.1 | Substructure | DZ450/10.5-X | set | 1 | ,10.5m, 8.91m, 4500KN,:12.25mX10.76m,:5''7000m, :2200KN.API Spec 4F. Swing up rising, height to drill floor:10.5m, height to rotary beam:8.91m, rated load of rotary beam:4500KN, drill floor area: 12.25mX10.76m,setback capacity: 5''DP 7000m, setback load:2200KN. The substructure meet API Spec 4F. |
| 2.2 | Dog House | set | 2 | ,,,,. The dog house in the left equip with EXPF Air Conditioner, the house divide into three rooms, the first room put hydraulic power station, the second room put office furniture and BOP Control Console, the third room put Electric Cabinet for mast and drill floor. ,:,,,,,(). The dog house in the right equip Tools House, can be divide into two rooms, the first room put well head tools, the second room is repair room equip with tool kit, worktable, EXPF air conditioner, one set repair tools for equipments and electricity. | |
| 2.3 | Mud Umbrella and Mud Retrun Pipe | set | 1 | ||
| 2.4 | Horizontal Slide of Drilling Tools | set | 1 | 2,.2000 mm, 1070mm, 17000mm. Consist of two sector, washmarking. Width:2000mm, height:1070mm, total length:17000mm. | |
| 2.5 | V-door Ramp | set | 1 | -1.8m width -1.8m | |
| 2.6 | Drill Pipe Rack | pcs | 8 | ,9000mm,1070mm Triangle, length:9000mm, height:1070mm. | |
| 2.7 | Moving Device of BOP | FY-50Y | set | 1 | ,,50. Hydraulic type, include lead rail, total lifting capacity:50Ton. |
| 2.8 | Hydraulic Cathead | YM-16-II | set | 1 | |
| 2.9 | Hydraulic Rotation Cathead | XYM-5 | set | 1 | |
| 2.10 | Pneumatic Winch | XJFH-5/35 | set | 2 | -5. Lifting capacity-5Ton. |
| 2.11 | Wireline | 6X19S-1WRC-IPC | М. | 1200 | 38mm, API Spec 9A. With dia.38mm. the wireline meet API Spec 9A. |
| 2.12 | Wireline Spooler | set | 1 | ,. Include motor, drum and reducer. | |
| 2.13 | Mouse Hole | .pcs | 1 | ||
| 2.14 | Rat Hole | pcs | 1 | ||
| 2.15 | () Air Storage Tank(mounted on the skid) | 1.5m3 | pcs | 2 | |
| 2.16 | Escape Slide | set | 1 | ||
| 2.17 | () Hydraulic Bumper Device(used to lift mast and substructure) | set | 1 | 4,,. Consist of 4 pcs hydraulic cylinder, control box, pipelines, pipeline connections etc. | |
| 2.18 | Hydraulic Lifter | set | 1 | ||
| 2.19 | , Walkway, Handrail and Ladder | set | 1 | 1200mm. The height of handrail is 1200mm. | |
| 2.20 | Cable Tray | set | 1 | ||
| 3 | |||||
| 3.1 | (RL-PS-70) Drawworks(include RL-PS-70 Type Hydraulic Disc Brake) | JC70 | set | 1 | :1470KW(2000HP);:485KN;:38mm(1-1/2in);:62;(x):770mm x 1310mm;. Max.input power:1470KW(2000HP), max.fast line pull:485KN, wireline dia.:38mm(1-1/2''), drawworks speed: 6 F 2 R, drum size(D x L): 770mm x 1310mm, with LeBus grooving. |
| :.2 | - Auxiliary Brake-Magnetic Eddy Current Brake | FDWS70 | set | 1 | |
| 3.3 | Cooling Device of Drawworks Brake System | set | 1 | 2(3 KW),:30m3. With 2 sets centrifugal pump(motor power:3KW), water tank volume: 30m3 | |
| 3.4 | Crown-O-Matic | set | 1 | ||
| 3.5 | Driller's Console | set | 1 | ,,,,VFDMCC,. Integrate the drawworks control, drilling parameter instrumentation, pneumatic control, hydraulic control, VFD and MCC control etc, equip with video-supervising system and wellsite communication system. | |
| 4 | |||||
| 4.1 | Travelling Block | YC-450 | set | 1 | :4500KN;:6;:1524mm;: 38mm(1-1/2″).:6 × 7. API Spec 8A. .max.hook load:4500KN, 6 No. Sheaves with dia.1524mm, wireline dia.38mm(1-1/2″), Lines:6 x 7, the travelling block meet API Spec 8A. |
| 4.2 | Hook | DG-450 | set | 1 | :4500KN;:220mm;:180mm;:200mm.API Spec 8A. Max.hook load:4500KN, main opening size:220mm, assist hook dia.:180mm, spring stroke:200mm. The hook meet API Spec 8A. |
| 4.3 | () Swivel(with spinner) | XSL-450 | set | 1 | :4500KN;:300r/min;: 75mm;:6-5/8'' REG-LH;:35MPa(5000psi).API Spec 8A. Max. Static hook load:4500KN, max.rpm: 300r/min, bore dia.75mm, connection: 6-5/8'' REG-LH, max.WP: 35MPa(5000psi). The swivel meet API Spec 8A. |
| 5 | |||||
| 5.1 | Rotary Table and Master Bushing | ZP-375 | set | 1 | :952.5mm (37-1/2'');:5850KN;: 300rpm;: 3.56:1.API Spec 7К. Rotary table opening dia.: 952.5mm (37-1/2''), max.static hook load:5850KN, max.RPM:300rpm, gear ratio: 3.56:1. the rotary table meet API Spec 7K. |
| 5.2 | Kelly Bushing | set | 1 | ||
| 5.2.1 | 5-1/4'' 5-1/4'' Kelly Roller Bushing | pcs | 1 | . Spuare Kelly | |
| 5.2.2 | 3-1/2'' 3-1/2'' Kelly Roller Bushing | .pcs | 1 | . Spuare Kelly | |
| 5.3 | Rotary Table Bushing | set | 1 | ||
| 5.3.1 | 1# 1# Bushing | pcs | 1 | 9-5/8''-13-3/4''. For 9-5/8''-13-3/4'' casing | |
| 5.3.2 | 2# 2# Bushing | pcs | 1 | 7''-9-5/8''. For 7''-9-5/8'' casing | |
| 5.3.3 | 3# 3# Bushing | pcs | 2 | 2-3/8''-7''. For 2-3/8''-7'' piping operation | |
| 5.3.4 | Bushing Elevator Link Device | pcs | 2 | ||
| 5.4 | Rotary Table Independent Device | set | 1 | ,,,. Include heavy duty skid, gear reducer, transmission shaft, inertia brake etc | |
| 5.5 | Motor to drive Rotary Table | YAFS600-423 | .set | 1 | 600KW |
| 5.6 | The Bit Breake with folowing bit diameter: - Ф444,5 1 pcs - Ф311,1 1 pcs - Ф215,9 1 pcs | 31 3 pcs/set | 1 | ||
