Nylon Cable Tie Mounting Machine with Self Adhesive System

US$15,000.00 1 set (MOQ)

Basic Info.

Model NO.
UP-140T
Type
Tube Head Injection
Structure
Horizontal
Plastic Type
Thermoplastic
Plasticizing Way
Screw Type
Clamping Way
Hydraulic
Automation
Automatic
Computerized
Computerized
Certification
CE, ISO9001:2008
Heating Power
16kw
Machine Weight
6.3t
Tank Volume
350L
System Pressure
16MPa
Transport Package
Film Packing
Specification
5.8*1.55*2.15
Trademark
UP
Origin
China
HS Code
8474809090
Production Capacity
500sets Per Year

Product Description


Ningbo Union Power Machinery Co., Ltd. - China Servo Injection Molding Machine
A. Modulus of Capacitance: The position, size, and maximum allowable modulus of capacitance and minimum closure thickness of the injection molding machine guide pillar (Green column).
B. Nozzle Parameters: Spherical diameter of the nozzle, nozzle aperture, nozzle outer diameter, maximum nozzle extension length, positioning aperture.
C. Code Mold Parameters: Code mold hole, slot size.
D. Ejection Mechanism: The position of the ejection point and the diameter of the ejector rod, and if necessary, the ejection force and ejection stroke are also provided.
E. Mold Opening Stroke and Maximum Opening Distance.
Technical Parameters Model UP-140T
Injection Unit A B C
Screw diameter (mm) 38 42 45
Shot Volume (cm3) 215 260 302
Injection weight (g) 194 237 272
injection pressure (Mpa) 186 152 132
Screw speed (rmp) 215
Clamping Unit
Clamping force (KN) 1400
Open stroke (mm) 380
Max Mold height (mm) 450
Min Mold height (mm) 135
Space between tie bars(mm) 420*420
Ejector force (KN) 46
Ejector stroke (mm) 120
Others
Pump pressure (Mpa) 16
Motor/driving power (KW) 13(14)
Heating power (KW) 8.2
Machine dimension (M) 4.2*1.2*1.9
Machine weight (T) 3.4
Oiltank cubage (L) 190
