1. Manufacturer type and factory supply directly.
2. Rich-experience with plastic tarpaulin.
3. Quick delivery without delay.
| DATA SHEET |
| | | | Testing Method |
| WIDTH: | 150-320 cm | 250-320 cm | |
| 59-126 Inch | 98.4-126 inch | |
| Base Fabric: | 100% PES 1100dtex 7×7 | 100% PES 1100dtex 9×9 | DIN EN ISO 2060 |
| Composition Fabric: | 160 g/m2,4.7 OZ/YD2 | 200 g/m2,5.9 OZ/YD2 | DIN EN ISO 2286-2,BS 3424 Method 5B |
| Composition Coating: | 470 g/m2,13.8 OZ/YD2,PVC + Acrylic | 480 g/m2,14.1 OZ/YD2,PVC + Acrylic | DIN EN ISO 2286-2,BS 3424 Method 5B |
| Lacquering: | 1/1 | 1/1 | |
| Breaking Strength Warp: | 2200N/5cm,495LBS/2inch | 3000N/5cm,675LBS/2inch | DIN 53 354,BS 3424 Method,FS 100 |
| Breaking Strength Weft: | 1800N/5cm,405LBS/2inch | 2800N/5cm,630LBS/2inch | DIN 53 354,BS 3424 Method,FS 100 |
| Tear Strength Warp: | 250N,56LBS | 300N,67LBS | DIN 53 363,BS 3424 Method,FS 134 |
| Tear Strength Weft: | 250N,56LBS | 300N,67LBS | DIN 53 363,BS 3424 Method,FS 134 |
| Adhesion: | 100N/5cm,22.5LBS/2inch | 100N/5cm,22.5LBS/2inch | DIN 53 357,BS 3424 Method 9B,FS 5970 |
| Temperature Resistance: | -30ºC/+70ºC | -30ºC/+70ºC | DIN EN 1876-2,BS 3424 Method 10,FS 5874 |
| Light Fastness: | 7 to 8 | 7 to 8 | DIN EN ISO 877,BS 3424 Method 15 |
| Flammability: | B1 | B1 | DIN 4102 |
| M2 | M2 | NF P92-507 |
| CL2 | CL2 | UNI 8456 8457 |
| PASS | PASS | NFPA 701 |
| PASS | PASS | CSFM Section 13115 |
| Application: | The coated fabrics are used in the fields of construction, transport and entertainment facilities etc. |
Loading Capacity:17Tons/20'GP and 28Tons/40FT.
You Are Warmly Welcome To Visit To Linyi Lurun Tarpaulin Factory,Pls Don't Hesitate To Contact Us For More Information Or Any Other Questions.Thank you a lot!Warmly RegardsJack Xu
