Horizontal Directional Drill Equipment Xe420e Xz450 Plus Xz680A Xz960e

Product Description

ABOUT US:
As a leading Chinese machinery and truck exporter, we have a professional experience of 8years in this field. Besides our trucks of high quality, our international sales team will also provide you excellent logistics service and after-sales service. We will always do our best to solve all the problems and put our customer's interests in the first place.
We can supply:
1) ALL kinds of trucks.
(Dump truck, mining dump truck, tractor truck, truck trailer ,towing truck , water tank truck, concrete mixer truck, oil tank truck, garbage truck, cargo truck, port terminal tractor, refrigerated truck, truck mounted crane, fire truck, suction sewage truck, bus , etc)
2) All kinds of construction machinery.
(Wheel loader, excavator, folklift, cranes, paver, road roller etc.)
XZ450 horizontal directional drilling rig machine

Pluralities of advanced control technologies are adopted, including the PLC control, electro-hydraulic proportion control, load sensitive control, etc.

The drilling rod automatic disassembly and assembly device can improve the working efficiency, relieves the labor intensity and manual error operation of the operators, and reduces the construction personnel and the construction cost.

XZ450 HORIZONTAL DIRECTIONAL DRILL
ITEM		PARAMETER
Engine	Make	Cum
	Model	QSC8.3-C260
	Rated Power	194 KW / 2200 R/Min
Operation	Type	Rack and pinion
	Max. Thrust /Pullback Force	480/480 KN
	Max carriage thrust/pullback travel speed	42M/Min
	Max. Spindle Torque	23500 N·M
	Max. Spindle Speed	135R/Min
	Type	Self-Propelled Steel Track
	Ground Travel Speed	3.0 Km/h
Drill Rod/ Drill pipe	Diameter ×Length	Φ89 mm×4500mm
	Entry Angle	10~20°
Mud Pump	Max flow rate	600L/Min
	Max pressure	10
Overall Weight		13.3T
Overall Dimension		8800×2280×2610mm

---
