| Main Features: | | | |
| * Working table with handle rising | | |
| * Horizontal and vertical action | | |
| * Oscillating belt for scratch free sanding and prolonged belt life |
| * Precision ground, cast iron table easy to adjust for height |
| * Smooth, powerful 2200W Aluminum Motor | |
| * End table provided for curvature work | | |
| * Large side fence to support small work pieces | |
| * Mitre fence in T-slot rail for accurate mitring work | |
| * Large cupboard in the base for the storage of spare belts etc |
| * 100mm dust outlet port | | | |
| | | | | |
| 01) Motor: 2200W | | | |
| 02) Belt size: 2,515 x 152mm | | |
| 03) Belt speed (50Hz): 960m/min | | |
| 04) Belt speed (60Hz): 1,150m/min | | |
| 05) Work table size: 840 x 300mm | | |
| 06) Fence size: 700 x 60mm | | | | |
| 07) Table travel (up and down): 80mm | | | | |
| 08) Dust chute diameter: 100mm | | |
| 09) Packing size (two cartons): 620 x 470 x 620; | |
| | | 1,290 x 720 x 510mm | |
| 10) Net/gross weight: 148/171kg | | |
| 11) Units per 20-foot container: 42 | | |
