Tonghui Th1952 Multifunctional Digit Multimeter High Brightness VFD Dual-Display

Product Description

Product Description https://ckt2017.en.made-in-china.com/contact-info.html
Brief Introduction
TH1952 5 1/2 digit multimeter is a multi-functional, costeffective voltage/current/resistance/capacitance meter. It provides Max. 120000 count, Max. sampling rate 200 times/s, 0.012% DCV accuracy ,etc, which is the optimal selection for users.
TH1952 provides high brightness VFD Dual-display, which can display ACV/DCV or DCI, ACV/ACI and frequency .etc to improve the test efficiency and, clearer display.
TH1952 is configured with USB interface, and also communication software is provided for PC communication, data analysis, statistics, building system. TH1952 accepts SCPI command to be compatible with communication software. Also Handler interface is provided to receive the external trigger and output sorting signal for production line.
Technical Parameter

Test Function
Test Parameter			DCV, ACV, DCI, ACI, DCR, CP, FREQ, CONT, DIODE, TEMP
Mathematics Function			%, dB, dBm, REL, mX+b
Range			Auto, Manual
Display			High brightness VFD dual-display
Trigger Mode			INT/BUS/EXIT
Reading Hold			To find out best stable reading for each data block of the given reading number according to the given accuracy.
LimitationMeasurement			To judge HI,IN,LO and display, with ALARM for HI/LO
Calibration			Auto, Manual
External Trigger			Handle interface (external trigger and output sorting signal)
Communication Interface			SCPI command support for RS232 and USB interface
Performance parameter expression of uncertainty: ±(% of reading+% of full scale)
Reading Rate(reading/s)
Reading Rate			Fast			Slow
			1/2		1/2	1/2	1/2
DCV/DCI			80		15	15	4
ACV/ACI			80		15	15	4
Ω			80		15	15	4
DCV
Range			Min. Resolution			Max. Uncertainty(1 year)
100mV-1000V			1µV			0.012%+0.008%
DCI
Range			Min. Resolution			Max. Uncertainty(1 year)
1mA-100mA			10nA			0.05%+0.005%
1A			10µA			0.10%+0.008%
10A			100µA			0.20%+0.006%
ACV
Range	Frequency	Min. Resolution		Max. Uncertainty(1 year)
100mV-750V	20Hz-50Hz	1µV		1.00%+0.1%
	50Hz-10kHz			0.20%+0.08%
	10kHz-30kHz			0.80%+0.08%
	30kHz-100kHz			3.00%+0.2%
ACI
Range	Frequency	Min. Resolution		Max. Uncertainty(1year)
1mA -10A	20Hz-50Hz	10nA		1.0%+0.08%
	50Hz-2kHz			0.5%+0.08%
	2kHz-10kHz			2.0%+0.18%
Resistance
Range			Min. Resolution			Max. Uncertainty(1 year)
100Ω-1MΩ			10µΩ			0.05%+0.008%
10MΩ			100Ω			0.20%+0.008%
100MΩ			1kΩ			2.00%+0.005%
Capacitance
Range			Min. Resolution			Max. Uncertainty(1 year)
1nF			1pF			2%+0.8%
10nF-1000uF			10pF			1.0%+0.5%
10000uF			1uF			2%+0.5%
Frequency
Range	Voltage sensitivity	Min. Resolution		Max. Uncertainty(1year)
1Hz-1MHz	40mV rms	10µHz		0.005%+0.003%
Temperature
Range	Probe type	Min. Resolution		Max. Uncertainty(1year)
-10ºC-100ºC	PT500	0.1ºC		Probe accuracy±0.2ºC
Uncertainty is not assured if the temperature is out of the range

Detailed Photos
Packaging & Shipping https://ckt2017.en.made-in-china.com/company-Changzhou-Chuangkai-Electronic-Co-Ltd-.html
Company Profile https://ckt2017.en.made-in-china.com/product-list-1.html
Chuangkai Electronic Co., Ltd is leading company specialized in producing, developing & selling various types of measuring instruments and testing equipment, such as temperature data logger, LCR meter, DC resistance tester (micro ohm meter), digital power meter, power supply, transformer tester, battery tester, programmable DC electronic load, charger, temperature controller, tachometer, high voltage signal-amplifier, power amplifier, etc.
FAQ:
Q. How is your company's product after-sales service system?
A. The product warranty period is 12 months, we can provide lifetime maintenance. We have professional pre-sales and after-sales teams that can respond to you within 24 hours to resolve technical issues. We provide one-to-one after-sales service.
Q: Can you customize it?
A: Yes, we accept customization according to customer's specific requirements.
Q. How long is your lead time? If I want to customize instruments, how long will it take?
A. When order quantity is 1-10 units, we have ready stock goods, we can ship out within 3-5 working days after receipt of deposit; products required new production of common materials, usually the lead time is about 10-15 days; products requiring new production of special and rare materials, usually the lead time is about 20-30 days.
Q. What payment method do you accept?
A. Our company accept payment method of T/T (bank transfer), Western Union, PayPal and so on.
Q. What package do you use for your products? What shipping method do you use?
A.1. Our company use standard exporting carton for packing. 2. We ship via express courier (door to door service), by air, and by sea according to customers' requirements.
For more questions, please feel free to send inquiries to us.

---
