| US$368.00-475.00 | 1 Piece (MOQ) |
| OUTDOOR FIXED LED DISPLAY SPECIFICATION | ||||||||
| 01 | PIXEL PITCH | 2.5MM | 3MM | 4MM | 5MM | 6MM | 8MM | 10MM |
| 02 | MODULE SIZE | 320*160MM | 192*192MM | 256*128MM | 320*160MM | 192*192MM | 320*160MM | 320*160MM |
| 03 | MODULE RESOLUTION | 128*64 | 32*32 | 64*32 | 32*32 | 32*32 | 40*20 | 32*16 |
| 04 | PIXEL DENSITY | 160000/m² | 111111/m² | 62500/m² | 40000/m² | 27777/m² | 15625/m² | 10000/m² |
| 05 | LED LAMP | SMD1415 | SMD1921 | SMD1921 | SMD2727 | SMD3535 | SMD3535 | DIP346/ SMD3535 |
| 06 | THE OPTIMUM VIEWING DISTANCE | 2.5~100M | 3~100M | 4~100M | 5~100M | 6~100M | 8~100M | 10~100M |
| 07 | MAXIMUM POWER CONSUMPTION | 2500W/m² | 1700W/m² | 1000W/m² | 1200W/m² | 900W/m² | 1000W/m² | 650W/m² |
| 08 | AVERAGE POWER CONSUMPTION | 600W/m² | 400W/m² | 250W/m² | 300W/m² | 200W/m² | 250W/m² | 150W/m² |
| 09 | STANDARD CABINET SIZE | 960MMx960MM | 960MMx960MM | 1024MMx1024MM | 960MMx960MM | 960MMx960MM | 960MMx960MM | 960MMx960MM |
| 10 | CABINET RESOLUTION | 384x384 | 320x320 | 256*256 | 192*192 | 160*160 | 120*120 | 96*96 |
| 11 | CABINET WEIGHT | 45KG | 45KG | 50KG | 45KG | 45KG | 45KG | 45KG |
| 12 | DRIVING METHOD | 1/16 SCAN | 1/16 SCAN | 1/16 SCAN | 1/8 SCAN | 1/8 SCAN | 1/4 SCAN | 1/4 SCAN, 1/2SCAN |
| 13 | BRIGHTNESS(CD/m²) | ≥6500CD/m² | ||||||
| 14 | APPLICATION | OUTDOOR | ||||||
| 15 | PIXEL COMPOSITION | 1R1G1B | ||||||
| 16 | THE OPTIMUM VIEWING ANGLE | 140°/120° | ||||||
| 17 | FREQUENCY | 50 ~ 60Hz | ||||||
| 18 | REFRESH RATE | 3840Hz/s | ||||||
| 19 | BRIGHTNESS ADJUSTMENT | 0~100% 256 LEVELS | ||||||
| 20 | GREYSCALE | 16BITS AFTER CORRECTION | ||||||
| 21 | OPERATING TEMPERATURE | -20ºC-60ºC | ||||||
| 22 | OPERATING VOLTAGE | 220V /110V | ||||||
| 23 | OPERATING HUMIDITY | 10 ~ 90%RH NON-CONDENSING | ||||||
| 24 | COLOR TEMPERATURE | 6,500K ~ 9,500K ADJUSTABLE (6,500K DEFAULT) | ||||||
| 25 | IP LEVEL (FRONT/REAR) | IP65 | ||||||
| 26 | LIFETIME | ≥100,000H | ||||||
