Basic Info.
Processing Accessory
Manual Lathe
Guide Rail
Horizontal Guide Rail
Tool Holder
4-Way Toolpost
Controlling Mode
Artificial
Certification
GS, CE, RoHS, ISO 9001
Name
High Quality Gap Bed Lathe Machine Ca6280cx1500
Distance Between Centers
1500mm
Tool Post Type
4-Way Toolpost
Tailstock Quill Diameter
Mt5
Spindl Speed
16-1400rpm(24steps)
Transport Package
Wooden Case
Specification
3200x1140x1750
Production Capacity
100 Sets Per Month
Packaging & Delivery
Package Size
370.00cm * 114.00cm * 175.00cm
Package Gross Weight
3260.000kg
Product Description
HIgh Quality Gap Bed Lathe Machine CA6280Cx2000
| Model | Unit | CA6280C |
| Max. swing over bed | mm | 800 |
| Max. swing over carriage | mm | 540 |
| Max. swing in gap | mm | 1020 |
| Effective gap length | mm | 210 |
| Max. length of workpiece | mm | 2000 |
| Width of bed | mm | 400 |
| Section of turning tool | mm | 25x25 |
| Spindle speed | r/min | 16-1400 (24 steps) |
| Spindle bore | mm | Φ105 |
| Spindle taper | Morse | (Φ113 1:20) |
| Feeding number | kinds | 64 |
| Range of metric threads | mm | 1-192 (44 kinds) |
| Range of inch threads | | 2-24TPI (21 kinds) |
| Range of module threads | mm | 0.25-48 (39 kinds) |
| Range of diametral pitc threads | mm | 1-96DP (37 kinds) |
| Tailstock quill travel | mm | 150 |
| Tailstock quill taper | mm | Φ75 |
| Tailstock quill diameter | Morse | MT5 |
| Main motor | kw | 7.5 |
| Packing size | mm | 3700x1140x1750 |
| Weight | kg | 3087/3260 |
TENGZHOU BETA CO.,LTD. is a highly reputed professional Machine Tool manufacturer and exporter in CHINA. We focus on complete seals solution include seal making CNC machine, seal processing software, seal materials and cutting tools, the annual output quantity up to more than 1000 units.
Having focused on international market. We have placed the priority on both machines' quality and service. All machines will thoroughly follow every stage during manufacturing, assembling, final testing, packing and shipping, we promise that every provided machine will be strictly tested and be ready to operate before delivery.
>>
