ADS1299IPAGR Texas Instruments Analog Front End - AFE Low-Noise,8-Ch,24B AFE

Product Details

Product Description

Product Description
Factory
Mfr. #:
ADS1299IPAGR
Manufacturer: Texas Instruments
Product Category: Analog Front End - AFE
RoHS: Details
Series: ADS1299
Type: Biopotential
Resolution: 24 bit
Sampling Rate: 16 kS/s
Number of Channels: 8 Channel
Interface Type: Serial, SPI
Supply Voltage - Max: 5.25 V
Supply Voltage - Min: 4.75 V
Minimum Operating Temperature: - 40 C
Maximum Operating Temperature: + 85 C
Mounting Style: SMD/SMT
Package / Case: TQFP-64
Packaging: Reel
Packaging: Cut Tape
Packaging: kxxReel
Analog Supply Voltage: 4.75 V to 5.25 V
Architecture: Sigma-Delta
Brand: Texas Instruments
Development Kit: ADS1299EEGFE-PDK
Digital Supply Voltage: 1.8 V to 3.6 V
Features: Daisy-Chainable, GPIO, Oscillator, PGA
INL - Integral Nonlinearity: 8 ppm
Input Type: Differential
Moisture Sensitive: Yes
Number of Converters: 8 Converter
Operating Supply Current: 500 uA
Operating Supply Voltage: 4.75 V to 5.25 V
Pd - Power Dissipation: 42 mW
Power Consumption: 41 mW
Product Type: Analog Front End - AFE
Reference Type: External, Internal
Reference Voltage: 4.5 V
SNR - Signal to Noise Ratio: 121 dB
Factory Pack Quantity: 1500
Subcategory: Data Converter ICs
Unit Weight: 0.012720 oz
Documents (7)

---
