US$40.00-80.00
|
1 kg
(MOQ)
|
Basic Info.
Contraction Percentage
0.4%~1.4%
Tensile Strength
81~130MPa
Size
Max 260mm Dia. Per Customized
Advantage
High Performance
Application Filed
Medical / E/E / Semiconductor / Aerospace etc
Transport Package
as Per Customer′s Request
Specification
as per customer′s request
Production Capacity
500000 Sets Per Year
Product Description
Product Description
Factory Direct Sales Of Natural Color Black Anti Static Can Be Zero Cut CNC Engraving PEEK Polyetheretherketone bar Rod
| Material | Brand | Size (Rod) | Services | Application |
| PEEK | MBH | Dia. 4 /5/6/7/8/9/10/13/16/18/22/ 25/26/40/45/50/55/60/65/70/75 /80/85/90/100/130/160mm or customized | sheet/rod extrusion and machining and plastic modified services | medical, pharmaceutical, and semi-conductor, Aerospace, Auto etc. |
PEEK (abbreviation for PolyEtherEtherKetone) is a high performance semi-crystalline, engineering thermoplastic.
PEEK PLASTIC APPLICATIONS PEEK is used in some of the toughest plastic applications that require the tightest tolerances. These include medical device parts, medical implants, structural applications, ultra-high vacuum applications, valve seats, pump gears, high purity seals, electrical connectors, screws, impellers, wear blades, lab equipment, analytical equipment, columns, cable insulation, and more. PEEK PERFORMANCE Properties of PEEK plastic include high temperature performance, excellent wear properties, superior chemical resistance and outstanding toughness and strength. It also has excellent deformation under load characteristics, a high flexural modulus, and exhibits low smoke and toxic gas emissions when exposed to a flame. MACHINING PEEK In its solid state, PEEK is readily machinable by CNC milling machines and is commonly used to produce high-quality plastic parts that are thermostable and both electrically and thermally insulating. PEEK is often considered a superior high-end engineering plastic, in the same category as Delrin, PTFE or nylon. Properties
Very stable at high temperatures Replaces stainless steel dry running parts Excellent Chemical Resistance Good resistance to radiation (Gamma & X-Ray) Low flammability High mechanical strength Food compliant
| Exterior | light brown |
| Tensile Strength MPA≥ | 100 |
| Elongation at break % ≥ | 45 |
| M.T.ºC | 343 |
| Tg ºC | 143 |
