US$42,999.00-62,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Type
Tool Milling Machine
Milling Cutter Type
Angle Milling Cutter
Milling Cutter Structure
Indexable Type
Controlling Mode
Artificial
Automatic Grade
Automatic
Certification
CE, ISO 9001
Transport Package
Container Bulk Nude Frame
Production Capacity
100pieces/Month
Product Description
Road Construction Use Hydraulic System Cold Milling Machine Xm503kl 103kw
Products Description XM503/XM503KL road milling machine is an asphalt road maintenance and construction machine mainly used for the maintenance operations of municipal roads and as the auxiliary construction implement for large milling machines. It can realize the small-area digging and renovation of asphalt concrete pavements, including highways, downtown roads, airports, cargo yards, and parking lots, and can be used for the removal of road bulges, asphalt ripples, overlapping curves, and tracks and for the scuffing of cement roads and the milling of pavement jumps. It can realize the milling along edges and manhole covers. It can realize the road crushing function if the optional hydraulic pickaxe is installed and realize the milling of roadside rumble strips if the optional rumble wheel is installed. Featuring high working efficiency, simple construction processes, easy control of milling depth, easy and flexible operations, and good mobility, this machine is an ideal machine for repair, renovation, and maintenance of asphalt roads.
Product Paramenters
Item
| Unit
| XM503KL
|
Milling width
| mm
| 500
|
Maximum milling depth
| mm
| 210
|
Tool nose distance
| mm
| 15
|
Number of tools
| | 60
|
Rotor diameter with tool
| mm
| 750
|
engine model
| | SC4H-C140
|
Engine manufacturers
| | Shangchai
|
Rated speed
| rpm
| 2200
|
Rated power
| Kw
| 103
|
Displacement
| L
| 4.3
|
Fuel consumption at rated power
| l/h
| 26.2
|
Comprehensive fuel consumption
| l/h
| 10.5
|
Emission Standards
| | China-
|
Working speed
| m/min
| 0-30.7
|
Walking speed
| Km/h
| 0-7.5
|
Theoretical climbing ability
| %
| 60
|
Milling drum maximum ground clearance
| mm
| 210
|
Overall dimensions (length X width X height)
| mm
| 8185X1888X4080
|
Length X width X height (including conveyor belt)
| mm
| 6276X1888X2530
|
Length X Width X Height (not including conveyor belts)
| mm
| 3676X1888X2530
|
Conveyor belt size (length X width X height)
| mm
| 6000X860X860
|
Total weight
| kg
| 7550
|
Working weight
| kg
| 7950
|
Minimum milling radius
| mm
| 350
|
Maximum ground clearance of milling drum
| mm
| 210
|
