| US$6,000.00-28,000.00 | 1 set (MOQ) |
| 1 | Suitable to process | Color steel plate |
| 2 | Width of the plate | 914mm/1000mm/1200mm/1220mm/1250mm |
| 3 | Thickness of the plate | 0.15-0.8 mm |
| 4 | De-coiler | Manual one, can load 5 tons raw material |
| 5 | Rollers for forming | 14-22 rows |
| 6 | Diameter of the roller | 70-90 mm |
| 7 | Rolling material | Carbon Steel 45# |
| 8 | Main motor power | 5.5kw |
| 9 | Material of the cutting blade | Cr12 mov |
| 10 | Hydraulic cutting power | 4kw |
| 11 | Processing precision | Within 1.00mm |
| 12 | Control system | Delta PLC control |
| 13 | Side panel of machine | 16mm |
| 14 | Main structure of the machine | 350 H steel |
| 15 | Weight | About 5T |
| 16 | Dimensions | 8.5*1.6*1.6m |
| 17 | Voltage | 380V 50Hz 3phases(changeable as needs) |
| 18 | Certificate | CE/ISO |
| 19 | Custom | According to customer's requirements |
