Ca+12 2u Class H Professional Audio Power Amplifier for KTV DJ Sound System (3G)

Product Description

Are you looking for an amplifier that work steadily under harsh situation, meanwhile, at an affordable price. then, you shall definitely give us A try. Product Description Feature: Adopts A grade toroidal transformer, very close to no EMI, and deliver more delicate sound. Components are carefully selected to match the circuits design. All adopts AI automated mechanical plug-in and SMD production process. Improve the reliability and consistency of the product welding. Deliver high-quality sound and high damping factor, with ultra fast switching diode fan, to ensure a stable working state for a long time performance. This circuits design have been improved during the practical experience. And it will be continuously updated in the future as well.

Spec	CA+2	CA+4	CA+6	CA+9	CA+12	CA+18	CA+20	CA+30	CA+50	CA+80
8 ohms Stereo Power	2x250W	2x350W	2x500W	2x650W	2x800W	2x1100W	2x1300W	2x1500W	2x1800W	2x2000W
4 ohms Stereo Power	2x400W	2x550W	2x750W	2x1000W	2x1200W	2x1700W	2x2000W	2x2300W	2x2700W	2x3000W
2 ohms Stereo Power	2x550W	2x700W	2x1000W	2x1300W	2x1600W	2x2300W	2x2600W	2x3000W	2x3600W	2x4000W
8 BTL	800W	1100W	1600W	2000W	2500W	3500W	4100W	4700W	5500W	6000W
4 BLT	1100W	1500W	2100W	2800W	3400W	4700W	5500W	6400W	7400W	8000W
Frequency response	20-20000Hz(±0.3dB)
thd+N	>0.08%lKHz
S/N Ratio	>100dB
Slew Ratio	>30V/uS
Damping Factor	>500:1
Crosstalk InPut ImPedance	>90dB@lKHz 30Kfi(Balanced,Stereo) 15KO(Blanced,Paralled)
Input Sensitivity	0.775V/1.0V/1.4V
height	3U
Packing Diamention	648X585X205mm

Detailed Photos
Installation Instructions
After Sales Service we offer one year warranty for non-human damages, offer with parts and technical consultant assist to the repair.

Company Profile Since established in 2012 (former company named Enping Lixing Electronics Factory), our company has been focusing on the production and sales of professional power amplifiers. Through many years of running-in with the market, we have accumulated rich production experience, our products have been continuously improved, and our quality is unanimously recognized by our customers.
We adhere to the principle of people-oriented and service-oriented, actively responds to customers' requirements, and sincerely learn from customers' suggestions.
We are expecting your kind visit and sharing ideas .

---
