| TECHNICAL DATA | STANDARD FEATURES | ||||||||||
| Performance: | Cylinder | AIRTAC | |||||||||
| Throughput Speed | 10-12 Cases/Minute | Motor | G P G | ||||||||
| Sensor | OMRON | ||||||||||
| Case (Outside Dimensions) | 250-500 mm L 250-400 mm W 120-400mm H | PLC | SIEMENS | ||||||||
| Touch Screen | SIEMENS | ||||||||||
| Pre-caution for empty carton box | |||||||||||
| Case Types | Pre-caution for Tape used up | ||||||||||
| Wall Types | Single & Double Wall (test for multiple wall) | Safety door system | |||||||||
| Vertical forming box output | |||||||||||
| Bottom Seal | |||||||||||
| Tape | 48-72mm | ||||||||||
| Service Requirements | Certification | CE | |||||||||
| Air Supply | 6 Bar (80 Psi) | Machine Warranty | 1 year | ||||||||
| Dedicated Electric | 220V, 1ph, 50/60Hz | ||||||||||
| Machine Data | Optional | ||||||||||
| Magazine infeed Capacity | 100 cases (approximate) | Bottom seal | Hot glue | ||||||||
| Weight | 350 kg | For Small size box (48mm tape 15-20 ctn/min) | Length: 180-250mm Width: 80-200mm Height: 100-200mm | ||||||||
| Dimensions | 2000*2150*1740 mm L*W*H | ||||||||||
| Outfeed Pass Height | 550 mm +/- 10 mm | ||||||||||
| Engineer Drawing |
| FEATURE |
| Packaging Line | |||||||||||
| Carton Erector + flaps fold carton sealing machine + Carton edge Sealing machine | Carton Erector + flaps fold carton sealing machine + Carton edge Sealing machine + strapping machine for 4 side |
