New Urban Construction Mobile Heavy-Duty Isuzu Qingling 6X4 10wheels 8, 9, 10cbm Variable Capacity Mounted Mixing Concrete Cement Mixer Truck

Product Description

Chongqing Friends International Trade Co., Ltd.
Our factory is professional manufacturer in truck area, customized trucks can be made. As Qingling ( China ISUZU ) big First Level Dealer, we guarantee superior technical support service and our trucks are Brand-New with High-quality.
China ISUZU Qingling GIGA series heavy duty truck equals to Japan ISUZU GIGA series heavy duty truck, compatibly in loading capacity, spare parts, technical support and after-sales service, same excellent performance but more cost-effective and competitive price.
Product Description I. Details of 6x4 10 wheels Japan China ISUZU Qingling GIGA CYZ 8, 9, 10m³ 6×4 Heavy Duty Diesel Concrete Mixer Truck
Function: Concrete Mixer Truck ( also called cement drum truck, concrete construction mixer, concrete mixing truck ) is a vehicle designed primarily for transporting mixed concrete for building construction purpose. It is mostly used in the construction site with the dump truck , boom truck, water truck, concrete pump truck .....
Types: 1. According to vehicle size, there are medium concrete mixer truck, heavy-duty concrete mixer truck. 2. According to chassis drive type, there are 4X2 concrete mixer truck, 6X4 concrete mixer truck, 8X4 concrete mixer truck.
Features:
1. Using Japanese technology ISUZU GIGA Chassis, super power, larger displacement, with Stronger Engine performance.
2. Remove the urea system and cancel DPF.
3. Quality test from the production to the finish of the whole truck.
4. Professional and experienced technical team support to provide customized trucks with high quality & reasionalble price.
5. Genuine spare parts supply.
6. Prompt delivery. All the truck will be polished with wax before shipping and accordingly the truck type and destination port to choose the most suitable and cost-effective shipping way.
Product Parameters II. Specifications

Product name	ISUZU GIGA 6×4 10 Wheelers 8m³, 9m³, 10m³ Concrete Mixer Truck
Vehicle Dimensions, Weights & Capacities	Chassis brand	ISUZU GIGA CYZ VC61 VC66
	Overall dimension (L*W*H)	8570*2500*3890mm
	Wheelbase	3985+1370mm
	Curb weight	15,000 Kgs
	Gross weight	35,000 Kgs
	Axle loads	7000/26000Kgs (Two-Axis Group)
Chassis	Drive mode	6x4
	Cabin type	Standard roof one bed
	Seats	2 seats
	Steering	LHD
	Tyres	10+1 spare tyre
	A/C	Air conditioning
Engine	Enging model	6UZ1, 6WG1
	Fuel and engine Type	Diesel, 6 cylinders in-line
	Horse power	350HP, 380HP, 420HP, 460HP, 520HP
	Displacement	9.839 L, 15.681L
Other Standard Configurations	1	Power Steering System
	2	Air Conditioning
	3	ABS, Automatically Air-cut Brake
	4	Tubeless tyres
	5	Retro-Reflective Marking
	6	Free Maintenance Battery
	7	Central Lock
	8	Power Window
	9	USB, Radio
	10	Widened Bumper
	11	Aluminum Alloy Gas Tank
	12	Front Chrome Kit for option
Tops Mixer Tank Parameters	Mixer Drum Tank Mixing Volume	10m³ ( 8, 9 cbm can be customized )
	Pedding rate ( % )	69
	Feeding charging speed (m³/min)	≥3
	Residual rate ( % )	≤0.2
	Discharging speed (m³/min)	≤2
	Mixing speed (r/min)	0-14
	Slump scope/range (mm)	50-220
	Material	Strengthen high performance wear-resisting corrosion resistance alloy steel
	Hydraulic Pump brand	Rexroth/SAUER/ARK/ETON for option
	Hydraulic Motor brand	Rexroth/SAUER/ARK/ETON for option
	Reducer brand	ZFP/SAUER/TOPUNION/BONFIGLIOLI for option

Detailed Photos III. Photos
