| ITEM | DESCRIPTION |
| Dimensions(L*W*H) | 12,400*2,500*1,250mm |
| Wheelbase | 1,310mm |
| Loading Capacity | 30T |
| Trailer Weight | 10,000kg |
| Main beam Material | Q345B manganese steel plate |
| Main Beam Size | Height: 500mm, upper plate is 14mm, middle plate is 8mm, down plate is 14mm |
| Axle | 3*13 FUWA brand |
| Suspension | Leaf spring suspension/air suspension |
| Landing Gear | JOST brand two-speed, Manual operating Heavy duty 28ton |
| King Pin | 2” (50mm) or 3.5” (90mm) welded pin |
| Side Wall | 800mm height; 600mm,1000mm optional, Q235 steel plate |
| Twist Lock | 12pcs, THT |
| Brake System | Emergency braking system, air damping, Dual line pneumatic brake system; WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber (FUWA brand); Two pieces of 45L air tanks |
| Brake chamber | 4 Nos.× Double Chamber 2 Nos. ×Single Chamber |
| Electrical System | 24V/12V, 7 core socket, lights according to European/USA standards. |
| Toolbox | 1 box of standard tools |
| Tire | 12R22.5 ×8 Nos |
| Rim | 9.0-22.5 ×8 Nos. |
| Spare tire | 1 pc |
| Painting | Shot blast to SA 2.5 Standard before application of primer and polyurethane top coat. Total DFT not less than 100μm; Any color will be available |
