Core Equipment for Foundry - Core Shooter for Sand Core Making

Product Description

Product Parameters
Technological equipment for foundry - core shooter for sand core making:
- Automatic Sand cores making machine model ZH1190-L50 with CO2-process,
-Max core box size is 1100x900mm,
-Max core size 800x700x450mm;
-Good shooting area is 800x700mm,
-with100lt shooting head capacity,
-50kg max shooting volume,
-hydraulic station with power is 7.5kW ,
-sand shooting pressure is 0.3-0.45MPa ;
- General electric control panel;
- Pneumatic, Hydraulic and Electrical diagrams
- Operation and maintenance manual.
Automatic core sand mixing complex, model S206S completed with:
≥200kg sand hopper with supporting structure,
45kg pneumatic grid quantitative,
level prove, S206S bowl type sand mixer,
electronic control system,
2off 80lt barrel for binders,
2off liquid heating system,
2off liquid conveying system;
Product Description
Qingdao Huaxin Co., Ltd. specializes in producing foundry machinery for more than 20 years in china. We recommend this automatic cold box core shooting machine. The tooling is horizontal parting, cured by carbon dioxide gas, with an automatic sand mixing unit and liquid heating system to realize automatic sand loading, sand shooting and sand core making. The operation is simple. Welcome to consult.
Detailed Photos
Related product
There are so many kinds of foundry machinery at our factory , from sand preparation, sand molding machine , automatic molding line, core shooter machine, shot blasting machine , automatic casting line , pouring ladle and soon on.
so contact us , you can buy all which you need one !
Company Profile
Qingdao Huaxin is a proud partner of Foundry plants bringing more than 20 combined years of foundry design and productivity to the worlds foundries of all sizes.
Qingdao Huaxin is a professional industrial solution provider, specializing in foundry design and automation in foundry industry.
Qingdao Huaxin is a professional manufacturer in the design and installation of highly customized and high performance "Green Sand" sand preparation Systems,semi-auto/automatic molding machines,core shooting machine, shot blasting machine,automatic pouring machine and return systems for foundries which produce cast iron, cast steel and aluminum castings.
