5 Inch LCD Fpv Monitor DVR Receiver 32 Channel with Sunshade (TE981H)

Product Description

5 Inch LCD FPV Monitor DVR Receiver 32 Channel with Sunshade(TE981H)
TE981H is a new generation portable CCTV DVR FPV monitor with one-press open sunshade developed by our company.
It supports both wireless and wired cameras. Frequancy can be 1.2Ghz, 2.4Ghz, 5.8Ghz. Not only this,
It adds new function of photo, loop recording, power saving (auto shutdown, auto off-screen), etc.
This DVR is the ideal choice for security & protection, evidence & investigation,
Like police, household, sports, automotive industry, shops, etc...At the same time,
With its stylish and high-end appearance, it also becomes the fashion choice of leisure goods.
Advantages:
32chs 5.8Ghz receiver with -102dbi.
Frequency mode: 1.2Ghz, 2.4Ghz, 5.8Ghz, it won't bluescreen when signal weak.
Mini size and portable recorder with fashionable & new design;
One-press open sunshade can help you see clear underder sunshine.
5-inch HD screen (800X480pix), which provides clear and smooth image;
Built-in 3200mAh high capacity Li-battery provides super long recording time up to 9.5 hours;
Supports storage up to 32G TF card, which records up to 32 hours;
Folding hidden external antenna assures excellent wireless receiving;
Supports AV IN function: Receiving signal from wired cameras;
Supports AV OUT function: Connecting big sreen monitor.
Photo function: It can take, review & store pictures;
Overwrite: It supports loop recording, which can automatically overwrite when storage is full;
Seamless continuous record: No intermittent recording, it will not miss any detail and wonderfulness;
Support power-saving mode: Automatic shutdown, automatic off-screen;
It's of high compatibility, which supports almost all computer operating system, including MAC;
Supports multi-language.
Channels:

Model: TE981H		Wireless receiving channels
Receiving	5.8Ghz 32CHs	A1:5.740GHz;A2:5.760GHz;A3:5.780GHz;A4:5.800GHz A5:5.820GHz;A6:5.840GHz;A7:5.860GHz;A8:SPI B1:5.725GHz;B2:5.745GHz;B3:5.765GHz;B4:5.785GHz B5:5.805GHz;B6:5.825GHz;B7:5.845GHz;B8:5.865GHz C1:5.733GHz;C2:5.752GHz;C3:5.771GHz;C4:5.790GHz C5:5.809GHz;C6:5.828GHz;C7:5.847GHz;C8:5.866GHz D1:5.705GHz;D2:5.685GHz;D3:5.665GHz;D4:5.645GHz D5:5.885GHz;D6:5.905GHz;D7:5.925GHz;D8:5.945GHz
	2.4Ghz 8 CHs	A1: 2414MHz;A2:2432MHz;A3: 2450MHz;A4:2468MHz. A5:2490MHz;A6:2510MHz;A7: 2390MHz;A8:2370MHz
	1.2Ghz 24 Chs	A1:1080 MHz;A2:1120MHz;A3:1160MHz;A4:1200MHz A5:1240 MHz;A6: 1280MHz;A7:1320MHz;A8:1360MHz B1:1080 MHz;B2:1120MHz;B3:1160MHz;B4:1200MHz B5:1258 MHz;B6: 1280MHz;B7:1320MHz;B8:1360MHz C1:1080 MHz;C2:1120MHz;C3:1160MHz;C4:1200MHz C5:1010MHz;C6: 1040MHz;C7:1240MHz;C8:1280MHz

Specifications:

Wireless Receiving
	Sensitivity	-88dB
AV IN	TV system	NTSC / PAL
	Output voltage	3.6-4.2 V
AV OUT	TV system	NTSC / PAL
HD 5-inch LCD screen	Active area	108mm(W) X 64.8mm(H)
	Resolution	800 X 480 Pixel
	Luminance for LCM	300 cd/m2
Video	Resolution	720*576 / 720*480
	Video compress	MPEG-AVI 30fps
	Play format	MPEG-AVI

Specification

Audio	Frequency	20HZ-20KHz stereo
	Earphone Output	Left: 20MW+ right 20mW [16O](suit to largest volume)
	Speaker	1W
Photo	Format	JPG/JPEG
Storage	External SD card	TF card 1GB-32GB(optional)
	32GB recording time	10-32 hours
	1GB photos	15625pcs
Operating system	PC	Windows & Mac OS
	Port	USB 2.0
	Language	Multiple
Power	Voltage	DC 5V
	Current(receiving mode)	660MA
	Current( recording mode)	680MA

Specification

Power	Current(recording with off-screen mode)	340MA
	AC adapter	DC 5V 2A
	Built-in battery	Li-battery 3200Mah
Standby time	Wireless record	≥9.5 hours(off-screen); ≥5hours(on-screen)
	Wired record	≥12 hours(off-screen); ≥6hours(on-screen)*LED camera not included.
Size :( LX W X H )	Without sunshade	131mmx 90.5mm x 18mm
Size :( LX W X H )	With sunshade	131mmx 90.5mm x 28mm
Weight:	Without sunshade	215g
Weight:	With sunshade	260g

---
