Well digging water finder Well digging water measuring instrument groundwater source analyzer

Product Description

Product Description
Well digging water finder Well digging water measuring instrument groundwater source analyzer
1.Product Introduction
KT-SZ series natural electric field intelligent one-key mapping geophysical water exploration instrument: It uses the natural electric field as the working field source, based on the resistivity difference of underground rocks, ores or groundwater, to measure N different frequency electric field components of the natural electric field on the ground, and studies the abnormal changes of different geological bodies according to their change laws to achieve an electrical exploration method to solve geological problems. Because this method measures the electric component of the earth's electromagnetic field, it is called the natural electric field method; and we select the frequency band of the corresponding depth for measurement, that is, frequency selection, so it is also called the frequency selection method, so it is generally called the natural electric field frequency selection method. The instrument designed and produced according to this theoretical method is called the natural electric field frequency selection geophysical survey instrument, referred to as the natural electric field instrument or frequency selection instrument, which is used for geological exploration. Therefore, from a professional perspective, it should be classified as an electrical instrument among the geophysical instruments in the large category of geological instruments. From the application perspective, it can be called a prospecting instrument, a water finder, a cavity detector, a prospecting instrument, an engineering exploration instrument, a geothermal detector, an archaeological instrument, a well logging instrument, a water meter, a water finder, a prospecting instrument, etc. From the perspective of measuring the field source, it is also called a natural electric field meter, an audio electric field meter, an earth audio meter, etc. This instrument utilizes the natural electric field source of the earth and does not require an artificial electric field, i.e., it omits the clumsy power supply system, thereby achieving simple operation and a lightweight instrument. The data collected by the instrument is automatically presented in the form of curve graphs and geological profiles through the instrument's unique built-in calculation function. The geological layer structure can be clearly understood based on the profile, and specific information such as rock layers, ore bodies, and aquifers can be quickly determined. Product Parameters
Well digging water finder Well digging water measuring instrument groundwater source analyzer
2.Product Parameter

model	Measurement Depth	Controller	Channel Gain		Measurement Accuracy	Measurement Channel	Measurement Range		Measurement Data Unit
KT-100SZ	100m	32bit high speed 33CPU	1~20 Ten thousand times		0.001mV	4	0~1000mV Automatic range switching		Electric field components of different frequencies in the magnetotelluric field Vs''(mV)
KT-200SZ	200m	32bit high speed 33CPU	1~30 Ten thousand times		0.001mV	6	0~1500mV Automatic range switching
KT-400SZ	400m	32 bit high speed 33 CPU	1~50 Ten thousand times		0.001mV	8	0~2000mV Automatic range switching
model	Power consumption	A/D conversion	Input impedance	Measurement frequency	Working environment Temperature	Relative Humidity	Power	Weight	Display
KT-100SZ	about 4 W	8 bit 1Msps	≥10MQ	20 frequency	-20ºC~50ºC	S85%	Rechargeable battery	Host 0.65kg Gross weight 6.9kg	7-inch high-definition TFT LCD display (with touch screen)
KT-200SZ	about 4 W	16bit 1Msps	≥10MQ	3020 frequency	-20ºC~50ºC	≤85%
KT-400SZ	about 4 W	16bit 1Msps	≥10MQ	4020 frequency	-20ºC~50ºC	S85%

Detailed Photos

---
