US$14,900.00-99,800.00
|
1 Piece
(MOQ)
|
Basic Info.
Certification
CCC, ISO9001, CE
Customized
Non-Customized
Shank Length of Blank
5-50mm
Production Speed
120-140PCS/Min
Diameter of Bolt
6mm-36mm
After-Sales Service Provided
Video Technical Support, Online Support,Engineers
Transport Package
Seaworthy
Specification
4.3*2.3*1.8m
Production Capacity
1000 Set/Year
Product Description
Product Description
| Condition | New |
| Condition | New |
| Place of Origin | Zhejiang ,China |
| Brand Name | WORSKEY |
| Model Number | 14B-6S |
| Voltage | 380V-420V |
| Power(KW) | 22W |
| Dimension(L*W*H) | 3.0*2.0*1.5 |
| Weight | 4.5T |
| Certification | CE |
| After-sales Service Provided | Video technical support, Online support,Engineers available to service machinery overseas |
| Warranty | 1 year |
| Packaging Details | Wooden pallet/ container |
| Port | SHANGHAI ,NINGBO |
Six station and seven station nut forming machine are available, both standard machine and Extended Nut Forming Machine. The equipment has good stability, long service life and high production efficiency. Machine can make various nuts such as: Normal hex nuts, Extra thick nut, Flanged nut, Motorcycle link pin, Oil Plug screw, Hex socket lockup nut, Square nut, Weld nut, Cap nut, Blind Nut, Chain roller, Expansion anchor, Bicycle and Motorcycle Spare Parts, Some rivets, Non-standard fastener, etc. We also offer customization service according to user product requirements.
Model
| Unit
| 11B-6SL
| 14B-6SL
| 17B-6SL
| 19B-6SL
| 22B-6SL
| 24B-6SL
|
Forging station
| No.
| 6
| 6
| 6
| 6
| 6
| 6
|
Cut-off dia.(Max)
| mm
| 11
| 14
| 17
| 19
| 21
| 24
|
Cut-off length(Max)
| mm
| 25
| 30
| 35
| 35
| 30
| 60
|
Kick out length(Max)
| mm
| 30
| 40
| 45
| 60
| 60
| 80
|
P.K.O. length(Max)
| mm
| 15
| 19
| 20
| 20
| 25
| 24
|
Dies pitch
| mm
| 50
| 60
| 70
| 80
| 90
| 100
|
Forging power
| kgs
| 56000
| 120000
| 125000
| 185000
| 170000
| 300000
|
Ram stroke
| mm
| 120
| 160
| 160
| 220
| 240
| 280
|
Output for nut
| pcs/min
| 60-160
| 70-110
| 60-100
| 60-90
| 60-90
| 50-80
|
Main motor
| kw
| 11
| 22
| 30
| 45
| 50
| 55
|
Lubrication motor
| kw
| 1.5
| 2.2
| 2.2
| 2.2
| 2.2
| 2.2*2
|
Lubricant
| L
| 600
| 900
| 1000
| 1200
| 1500
| 1600
|
Approx weight
| T
| 5.5
| 8.8
| 10.5
| 18
| 24
| 32
|
Detailed Photos
Packaging & Shipping
FAQ
>>
