20.8mm CCTV Camera Lens 5MP F2.0 Fpv Wide Angle Security Camera Lens M12 Threaded Dia for IP Camera Panoramic, Black

Product Description

About this item Color: Black; Material: Glass , Plastic ; Focal Length Description: 6.03mm; Lens Type: Wide Angle;Outer diameter 14mm/0.55 inch; Thread Type:M12; Aperture D/f': F2.0; Package List: 1 x 2.1mm 5MP CCTV Camera Lens CCTV camera is widely used in homes, factories, shops, bars, parking lots, warehouses, etc. Suitable for monitoring indoor and outdoor areas to avoid accidents. Standard M12x0.5 screw connector, suitable for most types of surveillance cameras. NOTE: Products with electrical plugs are designed for use in the US. Outlets and voltage differ and this product may require an adapter or converter for use in your destination. Please check compatibility before purchasing. The camera glass lens adopts a multi-layer coating process, using industrial-grade optical glass. The multi-layer coating makes the image clear and lifelike, and the night vision is clear and visible. The wide angle allows more of the scene to be included in the photo and performs well in daylight. It can record and reflect the subject's movement speed and rhythm changes. Suitable for indoor and outdoor areas that require attention.
Sensor 1/2.7'' 1/3'' F/NO 2.8 TTL 20.8mm Smart Security Lens

NOTES		SPECIFICATION
Sensor		1/2.7''	1/3''
Focal length(EFL)		6.03mm±3%
F/NO(Infinite)		2.8±3%
Back Focal Length		9.3mm
FBFL		8.2mm
Objective Distance		1000mm-
FOV Angle		D:70°±3°	D:60°±3°
		H:54°±3°	H:48°±3°
		V:40°±3°	V:36°±3°
Optical Distortion		-17.7%	-13%
TV Distortion		-6.4%	-4.7%
Chief Ray Angle		11.8°±2°	10°±2°
TTL		20.8mm±5%
Relative Illumination		76%	82%
Head Size		φ11.5±0.1
Number of Elements and Type		5G
Lens length		11.5±0.1

Package:
Vacuum packaging to ensure the condition of the product during transportation
Company Information:

JIARUI is mainly engaged in the research and development of optical lenses, prisms, mirrors, large,medium and small lenses, optical lenses, photoelectric module technology. It is an optical lens based,core of optical module assembly, one modern science and technology enterprises of research and development, design, production .The main business scope is divided into five major subjects(optical lenses, optical lenses, optical integration, optical components, optical modules) and seven fields(vehicle, UAV field, biometrics field, AR/VR field, smart home security field, medical equipment field, visual sensor automation field.
FAQ Q1 When the goods will be delivered?
A1 Stock samples will be delivered within 3 days. For 1k lenses, 15-20days.
Q2 How do you control the products quality?
A2 No dust working enviroments, four times quality checking during production process.Use imported high-precision testing equipment.
Q3 What's your payment term?
A3 T/T is acceptable as usual.
Q4 What is the delivery methods?
A4 The goods can be delivered by sea or by air, by express
Q5 Is OEM & ODM available?
A5 Yes, OEM and ODM are both available
Q6 What's your minimum order quantity for this item?
A6 1 unit.
Q7 What is the Warranty for the products?
A7 If there is a quality problem, please kindly provide the pictures to show the problem by email. We will provide the compensation (replacements or pay back )according to the email.
Q8 Can free sample be available before making an order?
A8 Your samples fee will be refunded when you place volume order.

---
